Casio AL-100R Service Manual

— 14 —
CODE NO. PARTS NAME SPECIFICATION Applicable Q
Price
Code
R REMARKS
58
1004 7623
CONNECTOR M441196-1 Common 2 AK C
59
6906 9312
KNOB/SL M311859B-1 Common 2 AA C
60
1004 7645
PANEL SUB ASSY/CN M141193*2 AL-100R 1 BX B
60
1005 4407
PANEL SUB ASSY/CN M141193*4 AL-150R 1 BZ B
61
1005 3835
PLATE/DISPLAY/437 M341405-2 Common 1 AD C
62
1005 2387
SWITCH ASSY/POWER M341447*2 TK(M437) Common 1 BN C
83
1004 3510
LCD CG1903-TTP Common 1 CH B
Console PCB's
39
1005 2383
PCB ASSY/M437-CN1M M241563*1 TK(M437) Common 1 CX B
40
1005 2384
PCB ASSY/M437-CN2-3M M241564*1 TK(M437) Common 1 CX B
LED301-LED303,
LED316-LED323,
LED328
1000 5470
LED SLZ-190B-02-T1 Common 12 AA B
LED304-LED315,
LED324-LED327
1004 7537
LED SLI-332URCTB7 Common 16 AA B
LED329-LED331
1000 5471
LED SLZ-290B-02-T1 Common 3 AA B
LED351,LED363,
LED376-LED383
1000 5470
LED SLZ-190B-02-T1 Common 10 AA B
LED352-LED362,
LED364-LED375
1004 7537
LED SLI-332URCTB7 Common 23 AA B
LSI301
1004 3507
LSI UPD65881GB-031-8ES Common 1 AU A
LSI351
1004 3507
LSI UPD65881GB-031-8ES Common 1 AU A
Q321-Q331
1004 7535
TRANSISTOR RN2205(TPE4) Common 11 AA B
Q332-Q334
1004 7532
TRANSISTOR 2SC5720(TPE4) Common 3 AA B
Q351-Q361
1004 7535
TRANSISTOR RN2205(TPE4) Common 11 AA B
Q362-Q364
1004 7532
TRANSISTOR 2SC5720(TPE4) Common 3 AA B
SW301-SW344,
SW351-SW394
1004 7536
SWITCH/TACT SKQNAED010 Common 88 AA A
VR321
1004 7473
VOLUME RS30H1210C95B14 Common 1 AE A
VR322
1004 7472
VOLUME RS30H1110C95B54 Common 1 AD A
X351
2529 2032
OSCILLATOR/CERAMIC CSB1000J Common 1 AC B
BL assy
41
1005 2390
BACKLIGHT ASSY M341475*1 TK(M437) Common 1 CP B
42
1005 2391
PCB ASSY/LCD-1M M241561*1 Common 1 CJ B
IC301,IC302
2105 6394
IC/C-MOS TC7SET08FU-TE85L Common 2 AB B
LSI301
1004 3508
LSI ML9040-B03GA Common 1 AU A
LSI302
1004 7457
LSI MSM5259GS-K Common 1 AP A
1004 7644
CONNECTOR/14P SHR-14P-28-M437 Common 1 AU C
1004 7626
FACE/D M441229-1 Common 2 AA C
1004 7638
FACE/D M441230-1 Common 2 AA C
1004 7622
FILM M441195-1 Common 1 AC C
1004 7530
LED UY40675-9B1-B170 Common 3 AF B
1004 7624
PIECE/TOP 437 LEFT M441220-1 Common 1 AB C
1004 7625
PIECE/TOP 437 RIGHT M441221-1 Common 1 AB C
1004 7635
PLATE/BL M341387-1 Common 1 BE C
1004 7639
SPONGE M441232-1 Common 2 AA C
Other Electrical Parts
63
1004 7602
SPEAKER S16J75A Common 2 BL B
64
3831 1075
SPEAKER S05JH37A Common 2 AR B
65
1004 7604
TRANSFORMER TE-437-1M1 Common 1 CJ B 120V area
65
1004 7607
TRANSFORMER TE-437-2M1 Common 1 CJ B 230V area
66
1004 7585
FDD DF354H123F Common 1 CV B
Notes: Q -
Quantity per unit
R -
Rank
ITEM NO.
