Casio AL-100R Service Manual

— 15 —
CODE NO. PARTS NAME SPECIFICATION Applicable Q
Price
Code
R REMARKS
Components
4
1005 2376
BOARD ASSY/FRONT M241598*1 TK(M437) AL-100R 1 DA B
4
1005 8211
BOARD ASSY/FRONT M241656*1 TK(M438) AL-150R 1 DA B
67
6924 5121
SHAFT M440300A-1 Common 1 BA C
68
6924 5140
GEAR 4247002100 Common 2 AC C
69
1005 2371
BOARD ASSY/TOP M241596*1TK(M437) AL-100R 1 DQ X
69
1005 8210
BOARD ASSY/TOP M241658*1TK(M438) AL-150R 1 DS X
70
1005 2370
COVER ASSY/KEY M241595*1 TK(M437) AL-100R 1 DK X
70
1005 8209
COVER ASSY/KEY M241657*1 TK(M438) AL-150R 1 DN X
71
6926 9420
DAMPER/RUBBER M440598-2 Common 4 AA X
72
3719 5442
FFC/MLMPA N30315B1B05-UL2896 Common 1 AO C
73
1001 4480
STOPPER M440862A-1 Common 1 CK C
74
1004 7605
34P-CONNECTOR YAF11-0973 Common 1 AS C
75
1004 7594
3P-CONNECTOR EH-3P-75-M437 Common 1 AE C
1005 4204
CASE ASSY M141191*1 TK(M437) AL-100R 1 EA X
1005 8212
CASE ASSY M141191*2 TK(M438) AL-150R 1 ED X
1004 7376
FLOPPY DISK AL100R-DISK-1 Common 1 AM C
1005 2369
STAND ASSY/MUSIC M241594*1 TK(M437) AL-100R 1 CT X
1005 8208
STAND ASSY/MUSIC M241659*1 TK(M438) AL-150R 1 CX X
Stand
78
1005 2392
PEDAL ASSY M241592*1 TK(M437) AL-100R 1 DN C
78
1005 8213
PEDAL ASSY M241592*2 TK(M438) AL-150R 1 DN C
79
1005 2393
ST-SIDE SUB ASSY M341473*1 TK(M437) AL-100R 1 DE C
79
1005 8361
ST-SIDE ASSY M341473*3 TK(M438) AL-150R 1 DL C
80
1005 2397
ST-SIDE SUB ASSY M341473*2 TK(M437) AL-100R 1 DE C
80
1005 8362
ST-SIDE ASSY M341473*4 TK(M438) AL-150R 1 DL C
81
1004 7379
BACK/ST M341368-1 Common 1 CH X
82
1004 7378
SCREW SET M241602-1 Common 1 BW X
84
1005 2396
FOOT ASSY M341474*1 TK AL-100R 1 BY X
84
1006 4259
FOOT ASSY M341474*3 TK(M438) AL-150R 1 CC C
85
1005 2398
FOOT ASSY M341474*2 TK AL-100R 1 BY X
85
1006 4260
FOOT ASSY M341474*4 TK(M438) AL-150R 1 CC C
Ac cord
76
1005 4071
CORD ASSY/AC TK-M341449*2(M427) Common 1 AW C 120V area
1004 5709
CORD SET UC2NC-M001A Common 1 AK C USA, Canada
77
1005 4205
INLET ASSY/2P-AC M341448*2 TK(M437) Common 1 BK C 230V area
1004 5706
CORD SET EC2NC-M001A Common 1 AM C Europe
1004 5707
CORD SET BC2NC-M001A AL-100R 1 BD C UK
Notes: Q -
Quantity per unit
R -
Rank
ITEM NO.
