AP-25, AP-28 PARTS PRICE LIST
Item Code No. Part Name Specification Q Price Code R Remarks
Main PCB
1 1005 2246 PCB ASSY/M427-MA1M TK-M241553*1(M427) 1
EF A
BT1 3815 0679 BATTERY/LITHIUM CR2032/1HF1 1
AG B
IC1 2114 1218 IC/MONOLITHIC NJM2068MD(T1) 1
AD B
IC10 2105 5824 IC/L-MOS TC7SH32FU(TE85L) 1
AB B
IC11 2105 3773 IC/L-MOS TC7SH08FU(TE85L) 1
AB B
IC12 2105 3696 IC/L-MOS TC7SH04FU(TE85L) 1
AB B
IC13 1004 7449 IC/MOS RN5VD28AA-TR 1
AC B
IC14 2105 5712 IC/L-MOS TC7S04FU(TE85L) 1
AB B
IC2 1000 8350 LSI PCM69BU/2K 1
BA A
IC3 1002 1416 IC/MOS RN5RF35BA-TR 1
AE B
IC4,IC9 2105 6389 IC/L-MOS TC7SET04FU(TE85L) 2
AD B
IC5 2105 6083 IC/L-MOS TC7WU04FU(TE12L) 1
AD B
IC6 2105 6394 IC/L-MOS TC7SET08FU(TE85L) 1
AB B
IC7,IC8 2105 6576 IC/C-MOS TC74LCX245FT(EL) 2
AF B
LSI1 2012 5987 LSI TC190C020AF-001 1
BC A
LSI2 1004 9737 LSI MR27V3202E-81MA-N 1
BT A
LSI3 1005 4502 LSI UPD914AGM-3ED 1
CK A
LSI4 1004 3417 LSI CY62126BVLL-55ZIT 2
BR A
LSI6 1004 9738 LSI UPD703107GJ014-UEN 1
CE A
Q1 2259 2702 TRANSISTOR 2SB1188T100Q 1
AB B
Q2 2253 0715 TRANSISTOR 2SD1664T100R 1
AA B
Q3 2250 1162 TRANSISTOR 2SA1576AT106R 1
AA B
Q4 2250 1605 TRANSISTOR 2SC4081T106S 1
AA B
Q5 2250 1162 TRANSISTOR 2SA1576AT106R 1
AA B
X1 1004 7439 OSCILLATOR/CERAMIC CSTCV16.00MXJ0C4-T 1
AC B
X2 1002 1357 OSCILLATOR/CRYSTAL DSX151GA-22.5792M 1
AS B
X3 1004 7438 OSCILLATOR/CERAMIC CSTCR5M00G35-R0 1
AC B
Power supply PCB
2 1005 2244
PCB ASSY/M427-PS2M TK-M241554*1(M427) 1 CE A 120V area
2 1005 4065
PCB ASSY/M427-PS2M TK-M241554*2(M427) 1 CE A 230V area
D401-D404 1003 6785 DIODE 2A02B 4
AA B
D405-D408 2390 3022 DIODE 3BZ41(LC6-15) 4
AD B
D409-D412,
D414-D415
2315 3132 DIODE 1SS133T-77 6 AA B
D413 1003 8115 DIODE/ZENER MTZJT-775.6B 1
AA B
D416 2390 2828 DIODE RB441Q-40T-77 1
AA B
F401 1005 2231 FUSE 51MS010L 1
AC A 120V area
F401 1005 4029 FUSE 50T010H 1
AC A 230V area
F402,F403 1005 2230 FUSE 51MS040L 2
AC A 120V area
F402,F403 1005 4030 FUSE 50T040H 2
AC A 230V area
IC401 2114 5796 IC/MONOTITHIC NJM78M05FA 1
AE B
IC402 2114 5794 IC/MONOTITHIC NJM78M15FA 1
AE B
IC403 1004 3418 IC/MONOTITHIC LM4765T 1
BC B
IC404 2114 1421 IC/PHOTO COUPLER PC900V 1
AK B
IC405-IC406 2121 0072 IC/MONOTITHIC NJM2068DD 2
AD B
J401 3501 4816 JACK/DIN YKF51-5051 1
AH B
Q401-Q403•Q405 2250 1627 TRANSISTOR 2SC1740STPS 4
AA B
Notes: Q - Quantity per unit
R - Rank
- 10 -
