Item Code No. Part Name Specification Q
Price Code
R REMARKS
PS12,PS3,PS4M PCB's
3 1005 4068
PCB ASSY/M437-PS1 TK-M341450*2(M427) 1 CL B 120V area
3 1005 4069
PCB ASSY/M437-PS1 TK-M341450*3(M427) 1 CL B 230V area
4 1005 2252 SWITCH ASSY/POWER TK-M341447*1(M427) 1
AY C
5 1005 2253 PCB ASSY/M427-PS3M TK-M341444*1(M427) 1
CE B
6 1005 2251 PCB ASSY/M427-PS4M TK-M341445*1(M427) 1
CE B
7 1005 2248 PCB ASSY/M427-PS5M TK-M341446*1(M427) 1
CE B
F400 1004 7508 FUSE 50T025H 1
AC A 230V area
F400 1004 7399 FUSE 51MS032L 1
AC A 120V area
J402,J403 1004 7514 JACK/PHONE YKB22-5078 2
AG A
1005 2243 PCB ASSY/FRONT BOARD TK-M241577*1(M427) 1
CE B
Other electrical parts
8 1005 4031
TRANSFORMER TE-427-1M1 1 CW B 120V area
8 1005 4032
TRANSFORMER TE-427-2M1 1 CW B 230V area
9 1005 2227 SPEAKER S12J99A 2
CD C
1004 7593 2P-CONNECTOR-M437NW EH-2P-45-M437 2
AB C
1005 2225 CORE/FERRITE TFCK-16-8-13 2
AQ C
1005 2224 CORE/FERRITE TFCK-23-11-14 1
AR C
Keyboard unit
10 1004 6083 KEY ASSY M141175*1 TK(MLMP2) 1
EM B
11 6927 4030 BLACK KEY M140784-1 36
AG A
12 1005 2300 HAMMER ASSY/BLACK KEY (R) M341438*1 TK(MLMP) 9
BH B
12 1005 2301 HAMMER ASSY/BLACK KEY (G) M341439*1 TK(MLMP) 9
BH B
12 1005 2309 HAMMER ASSY/BLACK KEY (BK) M341440*1 TK(MLMP) 9
BH B
12 1005 2310 HAMMER ASSY/BLACK KEY (BL) M341441*1 TK(MLMP) 9
BH B
13 1005 2296 HAMMER ASSY/WHITE KEY (R) M341434*1 TK(MLMP) 13
BH B
13 1005 2297 HAMMER ASSY/WHITE KEY (G) M341435*1 TK(MLMP) 13
BH B
13 1005 2298 HAMMER ASSY/WHITE KEY (BK) M341436*1 TK(MLMP) 13
BH B
13 1005 2299 HAMMER ASSY/WHITE KEY (BL) M341437*1 TK(MLMP) 13
BH B
14 6928 4470 RUBBER/CONTACT M240957-2 1
AE A
15 6928 4480 RUBBER/CONTACT M240958-2 6
AH A
16 6928 4490 RUBBER/CONTACT M240959-2 1
AH A
17 6927 4090 WHITE KEY/A M140789-1 7
AH A
18 6927 4100 WHITE KEY/B M140790-1 8
AI A
19 6927 4040 WHITE KEY/C M140783-1 7
AH A
20 6927 4050 WHITE KEY/D M140785-1 7
AI A
21 6927 4060 WHITE KEY/E M140786-1 7
AH A
22 6927 4070 WHITE KEY/F M140787-1 7
AI A
23 6927 4080 WHITE KEY/G M140788-1 7
AH A
24 6927 4110 WHITE KEY/SA M140792-1 1
AM A
25 6927 4120 WHITE KEY/SC M140791-1 1
AN A
26 6928 5460 PCB ASSY M887T-KY1M M240951A*1 1
BO C
27 6928 5470 PCB ASSY M887T-KY2M M240952A*1 1
BT C
28 6928 5480 PCB ASSY M887T-KY3M M241019A*1 1
BM C
6927 4011 CAP/GUIDE/WHITE KEY M340958A-1 13
AE C
6927 4020 CAP/GUIDE/BLACK KEY M340959-1 36
AA C
1005 4481 CHASSIS SUB ASSY M140831E*1 1
CV C
Notes: Q - Quantity per unit
R - Rank
- 11 -
