— 15 —
N Item Code No. Parts Name Specification Q Price Code R Remark
MAIN PCB
N 1 1009 8415 PCB ASSY/M428-MA1M TK-RJM502154*001 1 DZ A
N LSI4,LSI5 1008 7835 LSI D442012AGYBB55XMJH 2 BI A
N LSI2 1008 7836 LSI MR27V6402G-0A3TP-N 1 BQ A
IC2 1000 8350 LSI PCM69BU/2K 1 BA A
LSI1 2012 5987 LSI TC190C020AF-001 1 BC A
N LSI6 1008 7837 LSI UPD703107AGJ133UEM 1 CC A
LSI3 1005 4502 LSI UPD914AGM-3ED 1 CK A
IC1 1004 7445 IC/MONOLITHIC NJM2068MD(T1) 1 AC B
IC7, IC8 2105 6576 IC/C-MOS TC74LCX245FT(EL) 2 AF B
IC3 6932 4101 IC/MOS RN5RF33BA-TR 1 AN B
IC13 1004 7449 IC/MOS RN5VD28AA-TR 1 AC B
IC14 2105 5712 IC/L-MOS TC7S04FU(TE85L) 1 AB B
IC4 2105 6389 IC/L-MOS TC7SET04FU-TE85L 1 AD B
IC6 6930 9991 IC/L-MOS TC7SET08FU(TE85L) 1 AC B
IC12 2105 3696 IC/L-MOS TC7SH04FU-TE85L 1 AB B
IC11 2105 3773 IC/L-MOS TC7SH08FU-TE85L 1 AB B
IC5 2105 6083 IC/L-MOS TC7WU04FU(TE12L) 1 AD B
X3 1004 7438 OSCILLATOR/CERAMIC CSTCR5M00G35-R0 1 AC C
X1 1004 7439 OSCILLATOR/CERAMIC CSTCV16.00MXJ0C4-T 1 AC C
X2 1002 1357 OSCILLATOR/CERAMIC DSX151GA-22.5792M 1 AS C
Q3 2250 1162 TRANSISTOR/CHIP 2SA1576AT106R 1 AA B
Q1 2259 2764 TRANSISTOR/CHIP 2SB1188T100Q 1 AB B
Q4 6930 0298 TRANSISTOR/CHIP 2SC4081T106R 1 AA B
Q2 2253 0715 TRANSISTOR/CHIP 2SD1664T100R 1 AA B
D4 1004 7442 DIODE/ZENER HZU2.7B2TRF 1 AA C
D1 2360 2856 DIODE/ZENER UDZTE-175.6B 1 AA C
D3 2390 2576 DIODE/CHIP SCHOTTKY RB501V-40TE-17 1 AB C
EF1/EF2 3025 1862 FILTER/EMI NFM51R00P206 2 AC B
BT1 1005 2229 LITHIUM BATTERY CR2032/1HF1 1 AG C
PS1 PCB
2 1005 4068 PCB ASSY/M437-PS1 TK-M341450*2 1 BO B 120V area
2 1005 4069 PCB ASSY/M437-PS1 TK-M341450*3 1 BP B 230V area
F400 1004 7505 FUSE 51MS050L 1 AC A 120V area
F400 1004 7508 FUSE 50T025H 1 AC A 230V area
PS2M PCB
N 3 1009 8414 PCB ASSY/M428-PS2M TK-RJM502159*001 1 DB B 120V area
N 3 1009 8934 PCB ASSY/M428-PS2M TK-RJM502159*002 1 DB B 230V area
IC403 1004 3418 IC/MONOLITHIC LM4765T 1 BC B
IC405/IC406 2121 0072 IC/MONOLITHIC NJM2068DD 2 AD B
IC401 2114 5796 IC/MONOLITHIC NJM78M05FA 1 AE B
IC402 2114 5794 IC/MONOLITHIC NJM78M15FA 1 AE B
IC404 2114 1421 IC/PHOTOCOUPLER PC900VONSZX 1 AK B
Q401-Q405 2250 1592 TRANSISTOR 2SC1740STPR 5 AA B
Q406, Q407 1002 5042 TRANSISTOR 2SD1468STPR 2 AA B
D409-D412, 2315 3132 DIODE 1SS133T-77 6 AA C
D414, D415
D419 2390 3018 DIODE 1T2 1 AA C
D401-D404 1003 6785 DIODE 2A02B 4 AA C
D405-D408 1004 7403 DIODE 1N5401-EP 4 AA C
D416, D420 2390 2828 DIODE RB441Q-40T-77 2 AA C
D413 1003 8115 DIODE/ZENER MTZJT-775.6B 1 AA C
D417, D418 1004 7557 DIODE/ZENER MTZJT-778.2B 2 AA C
J402 3612 0789 JACK YKB21-5010 1 AC A
J403 3612 0584 JACK YKB21-5012 1 AD A
J401 3501 4816 JACK/DIN YKF51-5051 1 AH B
F401 1005 4029 FUSE 50T010H 1 AC A 230V area
F401 1005 2231 FUSE 51MS010L 1 AC A 120V area
F402,F403 1005 4030 FUSE 50T040H 2 AC A 230V area
F402,F403 1005 2230 FUSE 51MS040L 2 AC A 120V area
Notes : Q - Quantity per unit
R - Rank
