— 16 —
N Item Code No. Parts Name Specification Q Price Code R Remark
PS3M PCB
N 4 1009 8420 PCB ASSY/M428-PS3M TK-RJM502160*001 1 DZ B
J404, J405 1004 7514 JACK/PHONE YKB22-5078 2 AG A
PS4M PCB
N 5 1009 8417 PCB ASSY/M428-PS4M TK-RJM502161*001 1 BC B
D400 2370 1417 LED SLP-135B-51 1 AA B
CONSOL PCB
N 6 1009 8418 PCB ASSY/M428-CN1M,CN2M RJM502165*001 1 C R B
LSI301 6932 4293 LSI UPD65881GK-062-9ET 1 AT A
Q307-Q309 1004 7532 TRANSISTOR 2SC5720(TPE4) 3 AA B
Q301-Q306 1004 7535 TRANSISTOR RN2205(TPE4) 6 AA B
D301-D318 2370 1416 LED SLZ-190B-03-T2 18 AA B
X301 2529 2032 OSCILLATOR/CERAMIC CSB1000J 1 AC C
VR301 2765 0280 VOLUME EWA-NAXCH1B14 1 AI B
VR302 2765 2187 VOLUME EWA-NFECH1B54 1 AG B
KEYBOARD PCB
D701-D876 2315 3132 DIODE 1SS133T-77 176 AA B
7 6928 5460 PCB ASSY/M887T-KY1M M240951A*1 1 BO C
8 6928 5470 PCB ASSY/M887T-KY2M M240952*1 1 BT C
9 6928 5480 PCB ASSY/M887T-KY3M M241019A:1 1 BM C
MAIN CASE UNIT
N 10 1009 8935 MAIN CASE ASSY TK-RJM502025*001 1 DO X
N 11 1009 8936 COVER ASSY/KEYBOARD TK-RJM502084*001 1 DH X
N 12 1009 8937 BOARD ASSY/FRONT TK-RJM502023*001 1 DA X
13 1004 7602 SPEAKER S16J75A 2 BL B
13A1004 7589NETM441191-1 2 AD C
14 3831 1075 SPEAKER S05JH37A 2 AR B
15 1005 4031 TRANSFORMER TE-427-1M1 1 C W B 120V area
16 1005 4032 TRANSFORMER TE-427-2M1 1 C W B 230V area
17 1005 4071 CORD ASSY/AC TK-M341449*2(M427) 1 AW C 120V area
18 1005 4067 2P AC INLET ASSY TK-M341448*1 1 AT B 230V area
N 19 1009 8938 F BRD ASSY TK-RJM502089*001 1 DI X
KEYBOARD UNIT
20 1004 6083 KY ASSY M141175*1 TK(MLMP2) 1 EM B
N 21 1009 6229 CHASSIS SUB ASSY M140831*003V09 1 C W C
22 6928 4470 RUBBER/CONTACT M240957-2 1 AE A
23 6928 4480 RUBBER/CONTACT M240958-2 6 AH A
24 6928 4490 RUBBER/CONTACT M240959-2 1 AH A
25 1005 2296 HAMMER ASSY/WHITE KEY ( R ) M341434*1 TK(MLMP) 13 BH B
26 1005 2297 HAMMER ASSY/WHITE KEY ( G ) M341435*1 TK(MLMP) 13 BH B
27 1005 2298 HAMMER ASSY/WHITE KEY (BK) M341436*1 TK(MLMP) 13 BH B
28 1005 2299 HAMMER ASSY/WHITE KEY (BL) M341437*1 TK(MLMP) 13 BH B
29 1005 2300 HAMMER ASSY/BLACK KEY ( R ) M341438*1 TK(MLMP) 9 BH B
30 1005 2301 HAMMER ASSY/BLACK KEY ( G ) M341439*1 TK(MLMP) 9 BH B
31 1005 2309 HAMMER ASSY/BLACK KEY (BK) M341440*1 TK(MLMP) 9 BH B
32 1005 2310 HAMMER ASSY/BLACK KEY (BL) M311441*1 TK(MLMP) 9 BH B
33 6927 4030 BLACK KEY M140784-1 36 AG B
N 34 1008 3392 WHITE KEY/C M140783-007V04 7 AF B
N 35 1008 3394 WHITE KEY/D M140785-007V04 7 AG B
N 36 1008 3408 WHITE KEY/E M140786-007V04 7 AF B
N 37 1008 3411 WHITE KEY/F M140787-007V04 7 AF B
N 38 1008 3452 WHITE KEY/G M140788-007V04 7 AF B
N 39 1008 3454 WHITE KEY/A M140789-007V04 7 AF B
N 40 1008 3456 WHITE KEY/B M140790-007V04 8 AF B
N 41 1008 3475 WHITE KEY/SA M140792-007V04 1 AJ B
N 42 1008 3473 WHITE KEY/SC M140791-007V04 1 AJ B
43 6927 4011 CAP GUIDE/WHITE KEY M340958-1 13 AE C
44 6927 4020 CAP GUIDE/BLACK KEY M340959-1 36 AA C
Notes : Q - Quantity per unit
R - Rank
