Casio CFX-9850GB PLUS Software Guide

7
2-12 Melting Point of p-dichloroben-
zene
Description : Determines the melting point of p-
dichlorobenzene.
Probe : Te mperature Probe
File Name : MELTPNT
2-13 Simple Pendulum
Description : Produces a sine wave based on
the movement of a simple
pendulum.
Probe : Voltage Probe
File Name : PENDULUM
2-14 Measurement of pH with Colo-
rimetric Density Meter
Description : Measures the acidity of rainwater.
Probe : Light Probe
File Name : PHMEASUR
Weight
Piano wire
To voltage probes
Black (G, –)
Blue (+)
Red (+5 to 10V)
Variable resistor
(Type A, 10k Ω)
Stand
}
500ml brown beaker
Opening for test tube
Light probe
Upper and lower
test tube openings
Made of three film cases
LED
Temperature
probe
Test tube
Paradichlorobenzene
Water
Beaker
Alcohol lamp

Casio CFX-9850GB PLUS Specifications

General

Digits	46 digits
Display size (HxV)	21 8 mm
Memory type	28kb
Battery type	AAA

Weight and Dimensions

Weight	215 g
Dimensions (WxDxH)	90 x 25 x 183 mm
