Casio CSF-5350

PARTS LIST
Q
N Item Code No. Parts Name Specification
5350 5550 5750
R
AT AQ EQ FQ IQ JQ
CPU Board Ass'y
D1 2390 0847 Diode MA718-(TX) 111111C
D5 2390 0364 Diode MA713-TX 111111C
IC1 2114 4795 IC TC74HC4066AF(EL) 110011B
IC4,IC11 2105 2884 IC XC62CP5002PR 222222B
IC6 2105 5474 IC XC61AN7202PR 111111B
IC7 2105 5481 IC XC61AN6702PR 111111B
IC9 2105 5222 IC TC74HC04AF(EL) 111111B
IC10 2105 5236 IC TC74HC32AF(EL) 110011B
IC12 2105 1561 IC TC7S04F-TE85R 110011B
LSI3 2012 4508 LSI UPD23C4001EJGW-C52 111111B
LSI4,LSI5 2012 1659 LSI TC551001BFL-10V(S) 001122B
LSI6,LSI7 2012 3192 LSI TC55257DFL-7085V 220000B
J1 3501 6538 Jack HSJ1169-012010 111111C
Q6 2259 0959 Transistor DTC114YKT-146 111111C
Q100 2250 1281 Transistor 2SA1179M5,M6,M7-TB 111111C
VR1 2765 1869 Volume MVR32HXBRN503 111111C
X1 2590 1967 Resonator CSTC4.30MG-TC 111111X
X2 2590 1288 Crystal C-002RX 111111X
19 6418 9180 Battery Plate - EF02DB36109 333333X
20 6418 9170 Battery Plate + EF01DB36106 333333X
The following electronic parts will be not supplied from CASIO.
C1~C4,C9 Chip Capacitor MCH312F105ZP 555555X
C7 Electrolytic Capacitor ECEA1AKA330I 111111X
C10 Electrolytic Capacitor ECEA1CKA220I 111111X
C19~C20 Chip Capacitor MCH315F104ZK 222222X
C37 Chip Capacitor MCH185A221JK 111111X
C41,C42 Chip Capacitor MCH185A150JK 222222X
C70 Chip Capacitor CM105W5R102K50AT 111111X
CB5~CB6,CB10, Chip Capacitor MCH183F104ZK 006600X
C5,C12,C35
CB7 Chip Capacitor MCH183F104ZK 110011X
R1 Chip Resistor MCR03EZHJ153 111111X
R2~R3 Chip Resistor MCR03EZHJ301 222222X
R10~R11 Chip Resistor MCR03EZHJ105 222222X
R16 Chip Resistor MCR03EZHG822 111111X
R17 Chip Resistor MCR03EZHG392 111111X
R18 Chip Resistor MCR03EZHG202 111111X
R19 Chip Resistor MCR03EZHG102 111111X
R20 Chip Resistor MCR03EZHJ752 111111X
R21,R26 Chip Resistor MCR03EZHJ473 222222X
R22,R23 Chip Resistor MCR03EZHF1003 222222X
R25 Chip Resistor MCR03EZHJ182 111111X
R27 Chip Resistor MCR03EZHJ102 111111X
R28 Chip Resistor MCR03EZHG105 111111X
R32,R100 Chip Resistor MCR03EZHJ000 002200X
R50 Chip Resistor MCR03EZHJ124 111111X
R71~R73 Chip Resistor MCR03EZHJ823 333333X
R74,R100 Chip Resistor MCR03EZHJ000 220000X
R75,R100 Chip Resistor MCR03EZHJ000 000022X
R102~R103 Chip Resistor MCR03EZHJ474 222222X
Notes: N – New parts Essential FQ, JQ : For B.O.S.S.
Q – Quantity used per unit Stock recommended EQ, IQ : Others
R – Rank Others
No stock recommended
R – A :
B :
C :
X :
— 20 —
