CTK-1100
– 15 –
SPEAKERF.
Unsolder two lead wires.F-1.
Undo four screws and then remove the speaker.F-2.
Lead wire (White)
Lead wire (Blue)
Lead wire (Blue)
Lead wire (White)
<Left Speaker> <Right Speaker>
