Casio CTK-1100 Service Manual & Parts Guide

CTK-1100
– 24 –
1: CTK-1100_DI
2: CTK-1100_EU
3: CTK-1100_UK
4: CTK-1100_US
1234
Main PCB (MDA1)
N 1 10368206 PCB ASSY/MDA1 TK-RJM510415*001 1111 BMain PCB
N CN8 10178633 WIRE/for speaker 1007TASC24100B4040 1111 XBlue (+)
N CN9 10366747 WIRE/for speaker 1007TASC24100W4040 1111 XWhite (-)
VR1 69304870 VARIABLE RESISTOR EVND8AA03B53 1111 X
LCD Contrast
Volume
D1-D8 10276977 DIODE L1SS400T1G 8888 X
IC3 10240586 IC XC6109N40ANR 1111 X
N IC1 10363061 LSI ML6756B31GAZ03A114 1111 C
IC2 10222381 LSI ST7066U-0A-QG 1111 C
Q1 69300298 TRANSISTOR 2SC4081T106R 1111 X
TH1 10245365 THERMISTOR TSM1A103J34D3RZ 1111 X
X1 10070555 RESONATOR CSTCW20M0X51-R0 1111 X
Power Amp PCB (PSA1)
N 2 10368207 PCB ASSY/PSA1 TK-RJM510417*001 1111 CPSA1 PCB
N CN205,CN206 10178633 WIRE/for speaker 1007TASC24100B4040 2222 XBlue (+)
N CN204,CN207 10366747 WIRE/for speaker 1007TASC24100W4040 2222 XWhite (-)
J201 35015103 JACK HEC3110-01-010 1111 BDC Jack
J202 10305218 JACK JY-6316B*01-070 1111 C
Phones/Output
Jack
IC201 10300598 IC TA8227APL-D12-H-T 1111 X
L202 10231919 COIL RB53-856396NP 1111 X
L201 10231920 COIL RB53-856397NP 1111 X
N D203-D204 10261170 DIODE SRT14-A2 2222 X
D206 79114195 DIODE UDZSTE-175.6B 1111 X
N D201-D202 10371167 DIODE L1SS355T1G 2222 X
Q201 69300298 TRANSISTOR 2SC4081T106R 1111 X
N Q202 10217742 TRANSISTOR KTA1270-Y-AT/P 1111 X
Q203 10209015 TRANSISTOR KTD863-GR-AT/P 1111 X
Keyboard PCB
N 3 10368208 PCB ASSY/KYA TK-RJM508609*002 1111 CKYA PCB
D801-D830,
D832
10301580 DIODE LM1MA142WAT1G 31 31 31 31 X
4 10078918 SPONGE-40-100 M440962-001V01 1111 X
5 69268840 FABRIC TAPE-4-10 M440684-1 3333 X
Keyboard unit
6 10304687 WHITE KEY/CB TK-RJM507243*002 4444 C
7 10304688 WHITE KEY/CS TK-RJM507244*002 1111 C
8 10274032 BLACK KEY/10P RJM506595-001V02 2222 C
9 10274160 BLACK KEY/5P RJM506595-002V02 1111 C
10 10163902 RUBBER CONTACT/CB RJM503854-001V01 4444 B
11 10163903 RUBBER CONTACT/CS RJM503855-001V01 1111 B
Specification
Price
Code
R Remarks
Q'ty
N Item Code No. Parts Name

Casio CTK-1100 Specifications

General

MIDI-keyboard number of keys	61 keys
Product color	Black
Pitch bend wheel	Yes
Interface	-
Dimensions (WxDxH)	949 x 304 x 93 mm
Power consumption (typical)	7.7 W

Weight and Dimensions

Weight	3300 g
