E-9
General Guide
1
POWER/MODE switch
2
MAIN VOLUME slider
3
SYNCHRO/FILL-IN button
4
START/STOP button
5
ACCOMP VOLUME button
6
TRANSPOSE/TUNE button
7
TEMPO buttons
8 Speakers
9 Song Bank list
0 Display
A Rhythm list
B Tone list
C CHORD root names
D Percussion instrument list
E RHYTHM button
F TONE button
G
SONG BANK button
*
Attachment of the Score Stand
Insert both ends of the music stand provided
with the keyboard into the two holes on the
top surface.
Rear Panel
Q
PHONES/OUTPUT terminal
R
DC 9.5V terminal
H [+]/[–] buttons
• Negative values can be changed only by using [+] and
[–] to increase and decrease the displayed value.
I Number buttons/Chord specification buttons
• For input of numbers to change displayed settings.
• For input of chord specification data when using the
Chord Book.
J
REW button
K
FF button
L
STOP button
M
PLAY/PAUSE button
N
LEFT ON/OFF button
O
RIGHT ON/OFF button
P
CHORD button
Q R
CTK1100_e_08-16.p65 10.3.9, 5:14 PM9
