English
General Guide
EN-3
• The following explains the meaning of the $ symbol that appears on the product console and with the key names below.
$ : Indicates a function that is enabled by holding down the button for some time.
1
P(POWER) button ☞EN-6
2
VOLUME slider ☞EN-6
3
FUNCTION button ☞EN-4
4
METRONOME, $ BEAT button ☞EN-7
5
TEMPO buttons ☞EN-7, 19, 31
6
REPEAT, INTRO button ☞EN-18, 30
7
REW, NORMAL/FILL-IN button ☞EN-18, 30
8
FF, VAR./FILL-IN button ☞EN-18, 30
9
PAUSE, SYNCHRO/ENDING button ☞EN-18, 30
bk
PLAY/STOP, START/STOP button ☞EN-11, 17, 27
bl
PART SELECT, ACCOMP/$ CHORDS button
☞EN-20, 28
bm
TONE, SAMPLING DEMO button ☞EN-8, 11
bn
RHYTHM, ONE TOUCH PRESET $ button
☞EN-12, 27, 31
bo
SONG BANK button ☞EN-11, 17
bp
Number buttons, [–]
/
[+] keys ☞EN-4
bq
SAMPLED TONES/EFFECTS 1,
LISTEN button ☞EN-14, 23
br
SAMPLED TONES/EFFECTS 2,
WATCH button ☞EN-14, 23
bs
SAMPLED TONES/EFFECTS 3,
REMEMBER button ☞EN-14, 24
bt
SAMPLED TONES/EFFECTS 4, NEXT button
☞EN-14, 22
ck
SAMPLED TONES/EFFECTS 5, AUTO button
☞EN-14, 25
cl
VOICE PERCUSSION, LESSON button ☞EN-15, 22
cm
Speakers
cn
Song Bank list
co
Built-in microphone
cp
Display
cq
SAMPLING button ☞EN-11
cr
Rhythm list
cs
Tone list
ct
CHORD root names ☞EN-28
dk
Percussion instrument list ☞EN-8
dl dm
dn do dp
dl
USB port ☞EN-32
dm
SUSTAIN jack ☞EN-9
dn
AUDIO IN jack ☞EN-11, 35
do
DC 9.5V terminal ☞EN-5
dp
PHONES/OUTPUT jack ☞EN-6, 35
