Casio CTK-6250 User Manual

Using the Tone Editor
E-48
DSP On Off
(DSP On/Off)
Specifies whether DSP should be applied (on) or not applied (oFF) to notes.
The following four settings become enabled when “on” is selected for this
setting.
oFF
*
, on
DSP Specifies the DSP to be applied to tones using DSP numbers (001 to 100:
Preset DSPs; 101 to 200: User DSPs). Selecting “ton” applies the initial preset
DSP of each tone.
ton
*
, 001 - 200
DSP Type
(DSP Type)
Shows the DSP type number corresponding to the above DSP value that is set
automatically as the initial default setting.
*1
You can modify the initial default
setting and select a different DSP type.
01 - 46
*1
DSP Parameters 1
through 8
Shows up to eight parameters for “DSP Type”.
*2 *2
DSP RevSend
(DSP Reverb Send)
Adjusts how much reverb is applied to the post-DSP note. 0 - 40
*
- 127
*1 See “Preset DSP List” (page E-119) for information about the DSP types of each preset DSP.
*2 The number of DSP parameters, their content, and their setting ranges depend on the DSP type. For details, see “DSP Type
List” (page E-120) and “DSP Parameter List” (page E-121).
Parameter Name Description Setting Range
CTK6200_e.book 48 ページ ２０１１年１２月２７日 火曜日 午後８時２０分

Casio CTK-6250 Specifications

General

MIDI-keyboard number of keys	61 keys
Product color	Black, Red
Sound effects	Chorus, Equalization, Flanger/Digital Signal Processing (DSP), Reverberation
Volume control	Digital
Pitch bend wheel	Yes
Maximum polyphony (notes)	48
Interface	USB
USB ports quantity	1
Cables included	AC
Battery type	D
Number of batteries supported	6

Weight and Dimensions

Depth	384 mm
Width	948 mm
Height	122 mm
Weight	5700 g
