— 11 —
ADJUSTMENT
DISPLAY PCB
1) Items to be adjusted:
2) Adjustment and Test Point Locations
(TOP VIEW)
Item Measuring Instrument
Vop voltage setting Voltmeter
(BOTTOM VIEW)
VR501
TP2
TP1
