Casio CTK-671 Service Manual

N ITEM CODE NO. PART NAME SPECIFICATION Q PRICE CODE R
KEYBOARD UNIT
7 6922 2721 WHITE KEY SET/LT M312118A*1 4 AP A
8 6922 2731 WHITE KEY SET/LT M312118A*2 1
AP A
9 6906 8482 BLACK KEY SET 10P M140369B-3 2 AM A
10 6906 8592 BLACK KEY SET 5P M140369B-4 1 AI A
11 6922 2762 RUBBER/KEY M211704B-1 4 AF B
12 6922 2772 RUBBER/KEY M211705B-1 1
AF B
PANEL UNIT
13 1005 3647 LCD CG1902-TTP 1 BM B
14 1005 9358 SPEAKER 12K60SHA9225C 2 AT B
15 1004 7853 RUBBER/BUTTON M341423-1 1 AA B
16 1004 7854 RUBBER/BUTTON M241550-1 1 AA B
17 1004 7855 RUBBER/BUTTON M241543-1 1 AD B
18 1004 7856 RUBBER/BUTTON M241544-1 1 AD B
19 1004 7857 RUBBER/BUTTON M241545-1 1 AD B
20 1004 7858 RUBBER/BUTTON M241546-1 1 AD B
21 1004 7859 RUBBER/BUTTON M241547-1 1 AC B
22 1004 7860 RUBBER/BUTTON M241548-1 1 AB B
23 1004 7861 RUBBER/BUTTON M241549-1 1 AD B
24 1005 9359 CASE SUB ASSY/UPPER M241619*1 1
CZ B
25 6927 0510 CONTACT/SL CSB-08D 1 AD C
26 1002 7158 CONNECTOR M441141-1 2 AI C
27 6930 7200 PIECE/TOP 476-L M441142A-1 1
AA X
28 6930 7201 PIECE/TOP 476-R M441143A-1 1
AA X
29 6930 7202 FILM M441144A-1 1
AA C
30 1003 7738 SPONGE M441167-1 2 AA C
31 1003 0993 PLATE/BL M341362-1 1 AT C
32 1005 3931 PANEL/DISPLAY M141171-1 1 AQ C
33 6922 4480 DUMPER/KEY M412324-1 1 AE C
34 6921 5030 KNOB/SLIDE M311859-1 2 AA B
35 1006 2649 REFLECTOR M241321A-2 1
AO B
36 1003 7737 FACE/D M441174-1 1 AA X
D506,D509 1003 2149 LED FY4067S-2C1-B170 2
AD B
COMPONENT
37 1005 9361 CASE SUB ASSY/MUSIC M141274*1 1
CN X
38 6906 9252 PLATE/LOWER M240573B-2 1 AS X
39 1003 7742 BATTERY COVER SUB ASSY M341235*3(M476) 1 CF B
40 6903 2150 SPRING/BATTERY(+) M41330-1 1 AA X
41 6902 6141 SPRING/BATTERY(-) M41226A-1 1 AB X
6928 5280 STAND ASSY/MUSIC M340769*2 TK 1
AW X
Notes:N- New parts
Q- Quantity used per unit
R- Rank
- 14 -
