Casio CTK-711EX Service Manual

— 30 —
Item Code No. Part Name Specification Q R
L501 3841 1197 COIL LHL08TB101K 1 C
T501 3012 1470 INVERTER TRANS NT-07 1 B
CN1 ~ CN3 PCBs
8 6926 9070 PCB/ASSY (CN1M) M140751*1 1 B
9 6926 9080 PCB/ASSY (CN2M) M340815*1 1 B
10 6926 9090 PCB/ASSY (CN3M) M340816*1 1 B
IC301,302 2105 1239 IC/CMOS TC74HC164AP 2 A
LED301 2370 1383 LED TLR124(TPJ56,KT) 1 C
LED302~309 2370 1403 LED TLG124A(TPJ56) 8 C
VR301 2765 2178 VOLUME/SLIDE EWASC2C95B23 1 B
Keyboard
11 6922 2720 KEY SET/LT WHITE M312118*1 4 A
12 6922 2730 KEY SET/LT WHITE M312118*2 1 A
13 6906 8482 KEY SET/LS BLACK M140369B-3 2 A
14 6906 8592 KEY SET/LS BLACK M140369B-4 1 A
15 6926 2500 RUBBER/KEY M240699-2 4 B
16 6926 2510 RUBBER/KEY M240700-2 1 B
17 6926 9130 PCB/ASSY
(
KY1M
)
M140687*2 1 B
18 6926 9140 PCB/ASSY
(
KY2M
)
M140688*2 1 B
Bender
19 2765 1141 VOLUME RK1631110-50KB 1 B
20 6926 9450 KNOB/BENDER M340796-1 1 B
21 6926 9460 SPRING/BENDER M440654-1 1 C
Panel
22 3831 1081 SPEAKER S12J85A 2 B
23 3831 1082 SPEAKER S05JH39A 2 B
24 3335 6728 LCD LD-B10294E 1 A
27 6926 2540 CONNECTOR/FOR LCD M440459-2 2 C
28 6921 5030 KNOB/SLIDE M311859-1 2 B
29 6926 9280 RUBBER/BUTTON M240800-1 1 B
30 6926 9290 RUBBER/BUTTON M240801-1 1 B
31 6926 9300 RUBBER/BUTTON M240802-1 1 B
32 6926 9310 RUBBER/BUTTON M240803-1 1 B
33 6926 9320 RUBBER/BUTTON M240804-1 1 B
34 6926 9330 RUBBER/BUTTON M240805-1 2 B
35 6926 9340 RUBBER/BUTTON M140720-1 1 B
36 6926 9350 RUBBER/BUTTON M240807-1 1 B
37 6926 9360 RUBBER/BUTTON M240808-1 1 B
38 6926 9370 RUBBER/BUTTON M340788-1 1 B
39 6925 9380 RUBBER/BUTTON M240641-1 1 B
40 6925 9410 RUBBER/BUTTON M240640-1 5 B
41 6926 9250 PLATE/DISPLAY M240813-2 1 C
42 6918 1630 COVER/BATTERY M311164*1 1 B
43 3502 2318 CONNECTOR/LITHIUM BATT. MLES-A60-T 1 C
Accessory
6926 9540 STAND/MUSIC M140744-1 1 C
Notes: Q – Quantity per unit
R – Rank
