Linear PCB No. 3

FOB Japan

N Item Code No. Parts Name Specification M N.R.Yen R

C/I/N D Unit Price

F201 3025 0721 SIF filter SFSL6.0MDB12 0 1 10 C

F202 3851 1148 Ceramic discriminator CDSL5.5MC30B12 1 0 10 C

F202 3851 1141 Ceramic discriminator CDSL6.0MC30B12 0 1 10 C

F203 3850 1372 SIF trap TPS5.5MB 1 0 10 C

F203 3851 0553 Ceramic trap TPS6.0MB 0 1 10 C

Fuse

FU100 3632 0469 Fuse PI-251001(F10) 1 1 10 C

Oscillator

H300 2590 0651 Crystal oscillator HC-49U-C 1 1 1 C

ICs

IC200 2114 1827 Linear IC M51348FP-T1 1 1 1 B

IC270 2116 0119 OP AMP BA10358F-T1 1 1 10 C

IC300 2114 3479 Linear IC IR3P96-1 1 1 1 B

IC600 2114 2464 Linear IC NJM2070M-T1 1 1 5 B

IC700 2011 8337 LSI MSM6770GS-VK-675-F 1 1 1 B

IC701 2114 3458 IC S-81230SG-QB-T1 1 1 10 C

Jacks

JK100 3501 8281 Jack HEC0811-010010 1 1 10 C

JK200 3501 5439 Jack HSJ1456-01-210 1 1 20 C

JK250 3501 3773 Jack HSJ6063-01-410 1 1 5 C

JK600 3501 5439 Jack HSJ1456-01-210 1 1 20 C

Inductors

L101 3840 2374 Inductor EL0405SKI-101K-2 1 1 10 C

L102 3841 1386 Inductor EL0405SKI-331K-2 1 1 20 C

L200 3013 1393 Chip inductor LK2125-R82K-TP 1 1 20 C

L202 3013 1904 Chip inductor LK2125-150K-TP 1 1 20 C

L300 3013 1911 Chip inductor LK2125-330K-TP 1 1 20 C

L301 3013 1043 Chip inductor NLC322522-101K-TP 1 1 20 C

L310 3013 1043 Chip inductor NLC322522-101K-TP 1 1 20 C

L740 3013 1848 Chip inductor BK2125HS601-T 1 1 20 C

L756 3013 1911 Chip inductor LK2125-330K-TP 1 1 20 C

Transistors

Q101 2253 0133 Chip transistor 2SD1819A-R(TX) 1 1 20 C

Q110 2253 0133 Chip transistor 2SD1819A-R(TX) 1 1 20 C

Q111 2253 0308 Chip transistor 2SD1119-R(TX) 1 1 10 C

Q200 2252 0707 Chip transistor 2SC4238-(TX) 1 1 20 C

Q204 2210 8026 Chip transistor 2SB709A-R(TX) 1 1 20 C

Q270 2259 1435 Digital transistor DTC144EUWT106 1 0 20 C

Q272 2259 1834 Digital transistor DTA143TUWT106 1 0 20 C

Q600 2259 1645 Digital transistor DTA144EUWT106 1 1 20 C

Q710 2253 0133 Chip transistor 2SD1819A-R(TX) 1 1 20 C

Q750 2251 0189 Chip transistor 2SB1218A-R(TX) 1 1 20 C

Q760 2251 0189 Chip transistor 2SB1218A-R(TX) 1 1 20 C

Resistors

R105 2791 0742 Chip resistor ERJ-6GEYJ332V 1 1 20 C

R107 2791 0607 Chip resistor ERJ-6GEYJ333V 1 1 20 C

R108 2791 1919 Chip resistor ERJ-6GEYJ274V 1 1 20 C

R110 2791 1131 Chip resistor ERJ-6GEYJ271V 1 1 20 C

R113 2791 0720 Chip resistor ERJ-6GEYJ222V 1 1 20 C

R115 2791 0572 Chip resistor ERJ-6GEYJ101V 1 1 20 C

R150 2791 0607 Chip resistor ERJ-6GEYJ333V 1 1 20 C

R160 2791 1692 Chip resistor ERJ-6GEYJ680V 1 0 20 C

R160 2797 0245 Chip resistor ERJ-6GEYJ181V 0 1 20 C

R170 2792 0110 Chip jumper ERJ-6GEY0R00V 0 1 20 C

Notes: N – New parts

M – Minimum order/supply quantity

R – Rank

Quantity

— 17 —
