8. PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification QM N.R.Yen R
Unit Price
PCB ASS'Y
N 1 6414 7040 PCB Ass'y 377XXX0300R*1 1 B
(This assembly contains the following available elements.)
IC1 2105 4074 MOS IC S-80724AL-AM-T1 110 C
N LSI1 6413 3300 COF3010-F1 sub ass'y A340137*1 1 1 C
LSI2 2011 4088 LSI LC3564QM-85 1 1 C
N C1 6414 7260 Capacitor CB1000141R6 120 C
N C2,4~7 6511 7560 Chip capacitor CP001A432T8 520 C
C11,16~18 6511 7580 Chip capacitor CP0010430T3 410 C
N C12,13 6414 7270 Capacitor CB0220241R2 220 C
C15 2803 6813 Capacitor CB0011341R3 120 C
C19,20 6511 7570 Chip capacitor CP047B632T2 210 C
C21,22 6511 7520 Chip capacitor CP030F602T7 220 C
N R1 6414 7280 Chip resistor CC0185D10E6 120 C
N R3 6414 7290 Chip resistor CC0823D10E4 120 C
R5,6 6512 1420 Chip resistor CC0015D11T0 220 C
N X1 6413 4600 Resonator BD0079P4502 1 1 C
N 2 3335 5719 LCD AC1F8313A01 1 1 C
N 3 6414 1010 Shield tape L377 A440504-1 120 C
4 6410 0830 Shield tape L180 A414656-1 120 C
N 5 6414 7240 Sponge cushion FH100031202 220 C
N 6 5610 8620 Heat seal FX22P000004 1 1 C
N 7 5610 8590 Heat seal FX20P450101 1 1 C
COMPONENTS
N 8 6414 7130 Lower case FAB03771004 1 1 C
N 9 6414 7140 Battery spring (-) EF050EG2108 120 C
N 10 6414 7150 Battery spring (+) EF040FG2113 120 C
N 11 6414 7160 Battery spring (+-) EF060EG2321 120 C
N 12 6414 7050 Upper case FAA03771008 1 1 C
N 13 6414 7060 Key top frame ass'y KG037710005 1 1 C
N 14 6414 7070 Rubber sheet (50KL) LA037710001 1 5 C
N 15 6414 7080 Rubber sheet (1KL) LA0EG210022 1 5 C
N 16 6414 7090 Reset key KB00ST20000 120 C
N 17 6414 7100 Display plate EL5G0014101 1 5 C
N 18 6405 2970 Screw MAB20010300 620 C
19 6511 7220 Screw MAB10013209 620 C
N 20 6414 8770 Key top frame (SHIFT) KC037710009 1 5 C
N 21 6414 7210 Hard case FC103771007 1 5 C
N 22 6414 7220 Rubber foot LC050015408 110 X
N 23 6414 7190 Battery cover FAD03771001 110 C
N 24 6414 7200 Lable HGG00017109 120 C
N 25 6414 8780 Key top frame (ALPHA) KC037710106 1 5 C
N 26 6414 8790 Key top frame (EXE) KC037720004 1 5 C
Notes: N– New parts R – A :Essential
M– Minimum order/supply quantity B :Stock recommended
R– Rank C :Others
Q– Quantity used per unit X :No stock recommended
— 11 —
