— 3 —
2. SPECIFICATIONS
Display system: 13-character × 6-line liquid crystal display; 10-digit mantissa and 2-
digit exponent for calculations; displays binary, octal, hexadecimal,
sexagesimal values, fraction
Power supply: Two AAA-size batteries (LR03 (AM4) or R03 (UM-4))
Power consumption: 0.05W
Battery life*: Approximately 2,000 hours (contiuuous display of initial screen) type
LR03 (AM4)
Approximately 1,000 hours (continuous display of initial screen) type R03
(UM-4)
Approximately 2 years (power switch off) with LR03 (AM4)/R03 (UM-4)
* The batteries that have been installed in this unit when user pur
chased it had been used in the factory test, so it will be impossible to
fully satisfy this specifications when these batteries are used.
Auto power off: Power is automatically switched off approximately six minutes after last
operation.
Ambient temperature range: 0°C ~ 40°C (32°F ~ 104°F)
Dimensions: 17.5mm H × 77mm W × 157.5mm D (
3
/4" H × 3" W × 6
1
/4" D)
Weight: 120g (4.2 oz) including batteries
Accessories: Hard case
TYP [µA] MAX [µA]
ON (MENU) 320 457.5
OFF 11.2
Current Consumption
