5. PARTS LIST: MODULE QW-4762/4778
MODULE QW-4762
QW-4762A
T
1 QW-4762AT-91
2 QW-4762AT-92
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A
Rank ----------------------------------------
-
Important
C Rank ----------------------------------------
-
Not Important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
A
ttention to order
1. The most of normal re
p
air or initial re
p
air within 1
y
ear since released month can be done b
y
main
p
arts.
2. Minor
p
arts should be ordered carefull
y
in consideration of the actual usa
g
e of
y
our re
p
air and
y
our technical skills.
3. Main
p
arts should be ordered and stocked a
pp
ro
p
riatel
y
in consideration of
y
our
p
arts usa
g
e anre re
p
air usa
g
e for
similar models.
MAIN PARTS
Item Code No. Parts Name S
p
ecification R
12
10250688 MODULE/WITH MOVEMENT QW-4762AT-91 1
A
10250969 MODULE/WITH MOVEMENT QW-4762AT-92 1
A
1 76404704
A
NALOG BLOCK QW-2700MV-82TK 1 1
A
2 76410299 PCB ASS'
Y
RJQ536438*001V01TK 1 1
A
3a 10250500 LCD
(
3H-6H
)
S4762W-01THN 1
A
3b 10250966 LCD
(
3H-6H
)
S4762W-02THP 1
A
4a 10250499 LCD
(
9H-12H
)
S4762S-01THN 1
A
4b 10250965 LCD
(
9H-12H
)
S4762S-02THP 1
A
MINOR PARTS
Item Code No. Parts Name S
p
ecification R
12
5 10055369 COIL ASS'Y Q369455*1 1 1 C
6 10016598 CONTACT/BATTERY
(
-
)
Q366836-1 1 1 C
7 10201541 CUSHION 3766 RJQ527521-001V01 4 4 C
8 10243739 HOLDER/HOUR WHEEL RJQ533200-001V01 1 1 C
9 10260667 INTERCONNECTO
R
RJQ536615-001V01 2 2 C
10 10255006 LABEL RJQ524829-001V04 1 1 C
11 10137168 PLATE/TERMINAL 2787-1 RJQ515398-001V02 1 1 C
Notes: Q - Used quantity
R - Rank
A : Important
C: Not Important
Q'TY
Q'TY
- 14 -
