5. PARTS LIST: QW-2223
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank ----------------------------------------------
Very Important
B Rank ----------------------------------------------
Important
C Rank ----------------------------------------------
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name S
ecification A
licable Q R
7640 3617 MODULE/WITHOUT MOVEMENT QW-2223AT-01TK G-2400-1V/2V 1 A
1 1002 4518 LCD C2223-01P QW-2223AT-01 1 A
2 1001 6311 EL YEL-2171-A-01 QW-2223AT-01 1 A
3 7640 3596 PCB ASS'Y Q254630*1TK QW-2223AT-01 1 A
4 1001 0950 CAPACITOR/TRIMMER CTZ2E-30C-W2-P QW-2223AT-01 1 B
5 7110 6323 OSCILLATOR/CRYSTAL DT-26S11 QW-2223AT-01 1 B
6 7236 0286 CONTACT/BATTERY (–) 1650 Q357954C-1 QW-2223AT-01 1 C
7 7211 9631 CUSHION/506 Q49364-1 QW-2223AT-01 2 C
8 7211 0064 CUSHION/6 Q4914-1 QW-2223AT-01 1 C
9 7231 1952 HOLDER/BATTERY 2058 Q253743-1 QW-2223AT-01 1 C
10 1001 6309 INTERCONNECTOR/2171 Q466259-1 QW-2223AT-01 2 C
11 7233 0952 SHEET/INSULATION 1028 Q434476-1 QW-2223AT-01 1 C
12 1002 4512 SPACER/ 2171 Q466258-1 QW-2223AT-01 1 C
13 7230 0616 SPRING/COIL 1199-1 Q437728B-1 QW-2223AT-01 2 B
14 7201 9249 SPRING/COIL 675-3 Q413389A-1 QW-2223AT-01 1 B
15 7230 0497 SPRING/COIL 675-3 Q413389A-2 QW-2223AT-01 2 B
BATTERY/LITHIUM CR2016 QW-2223AT-01 1
For the
rices and minimum order/su
l
uantities of the above
arts, refer to the Parts Price List P.P.L.-562.
Notes: Q – Used quantity
R – Rank
— 9 —
To Next Page
