Casio GZ-50M User Manual

— 15 —
0
A
B
CH1
CH2
C
CH1
D
E
CH2
0
A
DAC output
UPD6376GS pin 11
Filter output
M5218AFP pin 1
B
C
Line out amp. input (L-ch)
C111
Line out amp. output (L-ch)
C161
D
E
Headphone amp. input
LA4525 pin 7
Headphone amp. output
LA4525 pin 1
Program change (Tone No)
Note No. (Key)
Velocity
: 078 (Whistle)
: 81 (A4)
: 127 (Maximum)
CH1
CH2
1 ms
CH1: CH2:
1 ms
50 mV
~
50 mV
~
CH1: CH2:50 mV
~
.5 V
~
CH1: CH2:10 mV
~
1 V
~
1 ms
