Casio HR-150TEC Service Manual & Parts List

— 2 —
2. DISASSEMBLY
1. Remove the battery cover and the battery.
2. Remove two screws.
Hook positions
3. Remove eight hooks and remove the lower case.
4. Unsolder five lead wires.
Black
Orange
Red
Yellow
White
5. Unsolder the cable.

Casio HR-150TEC Specifications

General

Type	Printing
Form factor	Desktop
Roll width	58 mm
Digits	12 digits
Digit comma separator	Yes

Weight and Dimensions

Weight	520 g
Dimensions (WxDxH)	165.5 x 285 x 67 mm
