Casio Privia PX-S1100 Connection Guide

EN-1
You can use the included Wireless MIDI & audio adaptor to pair the Digital Piano with a Bluetooth audio device and sound the
playback of the external device from the Digital Piano’s speakers.
• Before performing the pairing operation, turn down the volume levels of the Digital Piano and the external device.
• If external device notes sounded by this Digital Piano are distorted, lower the external device’s volume level.
• Due to Bluetooth characteristics, you may notice some lag in notes. If that happens, connect using a USB cable.
■ To pair the Digital Piano with a Bluetooth Audio Capable Device
1. Connect the Wireless MIDI & audio adaptor to the bl USB Type A port.
2. On the Bluetooth setting screen that appears on the external device, turn on the Bluetooth function if it
is off.
3. While holding down 3 FUNCTION on the Digital Piano, press the C{1 keyboard key.
This causes the Digital Piano’s Bluetooth indicator to flash, which indicates pairing standby.
• If the Digital Piano’s wireless function is turned off, it will turn on automatically.
4. Release 3 FUNCTION.
5. Use the setting screen of the Bluetooth capable audio device to select “WU-BT10 AUDIO” to pair with
this Digital Piano.
• When pairing is complete, the Digital Piano’s Bluetooth indicator stops flashing and a piano tone notification sounds.
• Now output from the external device will sound from the Digital Piano’s speakers.
• You need to turn on both the Digital Piano’s wireless function and the Bluetooth audio capable device’s Bluetooth function.
• To change the Digital Piano’s wireless settings, see “Enabling and Disabling the Digital Piano’s Wireless Function” (page EN-4).
• Information about the last Bluetooth audio capable devices connected to this Digital Piano is registered by the Wireless MIDI &
audio adaptor. Because of this, it can automatically perform Bluetooth audio pairing with the same device, so you will not need to
perform the Bluetooth audio pairing operation again.
Sounding a Bluetooth
®
Audio Capable Device (Bluetooth Audio Pairing)
Wireless MIDI & audio adaptor
bl USB Type A port
C1
A0
C2 C3 C4 C5 C6 C7
C8
C{1

Casio Privia PX-S1100 Specifications

General

USB port	Yes
Audio input	1
Bluetooth version	5.0
USB connector type	USB Type-A, USB Type-B
USB ports quantity	2
Battery type	AA
Power source type	Battery
Power consumption (min)	10 W
Number of batteries supported	6
Demo songs quantity	10
Transposition range	0 - 2 octave(s)
Product color	White
Sound effects	Brilliance, Chorus
Tones quantity	18
RMS rated power	16 W
Metronome tempo range	20 - 255 bpm
Metronome beats per bar	0, 9
Maximum polyphony (notes)	192
Number of transpose switches	12
Music memory capacity (songs)	60
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	232 mm
Width	1322 mm
Height	102 mm
Weight	11200 g
