Repair Item 3: The audio signal is not present in headphone Terminal.
6
Is the audio signal
present in “LINE OUT”
jack ?
3
* Check IC601.
* Check the circuit around IC601.
Yes
* Check IC301.
* Check the circuit around IC301.
No
Repair Item 4: A selected track number can’t be searched.
* Check the pickup.
* Check the FL wire connector.
* Check IC502.
4
Repair Item 5: “BATT” is not displayed on the LCD.
Is the level
“LOW” at pin 35 of
IC801 ?
5
* Check Q404.
* Check S402.
Yes
* Check LCD801.
* Check IC801.
No
To Next Page
