10. PARTS LIST
FOB Japan
N Item Code No. Parts Name Specification Q M N.R.Yen R
Unit Price
N LSI1 6409 2760 COB LSI C312133*1 1 1 1,010 A
LSI3 2011 2849 LSI (RAM) uPD43256AGU-1012LL 1 1 600 B
Q1 2259 0959 Chip digital transistor DTC114YKT-146 1 20 12 B
N DET1 2105 3297 CMOS IC S-80752AN-JG-T1 1 10 47 B
N REG1 2105 3290 Regulator S-81253SGUP-DIJ-T1 1 5 60 B
C1~4 2896 1400 Chip capacitor C1608JF1C334Z-TP 5 20 10 C
C5,6 2845 2534 Chip capacitor MCH185A180JK 2 20 4 C
C7 2845 2548 Chip capacitor MCH183F104ZK 1 20 6 C
C8,10,12 2845 1540 Chip capacitor MCH212F104ZK 3 20 4 C
C9,11 2805 0275 Electrolytic capacitor CE04C-1A100MS5 2 20 21 C
N D1 2390 2128 Chip diode MA740-(TX) 1 20 50 C
D2 2390 0364 Schottky diode MA713-TX 1 20 33 C
R4,20 2797 2051 Chip resistor ERJ-3GEY0R00 1 20 2 C
R5 2791 1170 Chip resistor ERJ-6GEYJ182 1 20 3 C
N R6 2797 0637 Chip resistor ERJ-6GEYJ473 1 20 2 C
R7 6510 4770 Chip resistor CC1001311C0 1 20 5 C
R8,9 2797 1078 Chip resistor ERJ-6GEYJ101 2 20 3 C
R10 2791 1871 Chip resistor ERJ-6GEYJ474 1 20 3 C
R13 2797 2520 Chip resistor ERJ-3GEAK206V 1 20 2 C
X1 7110 0642 Crystal oscillator DT-26S 1 1 57 B
JC1 3501 6538 Jack HSJ1169-012010 1 20 56 C
N 1 3335 4606 LCD CD418-TS 1 1 350 A
N 2 6409 6270 Heat seal FX200P40056 1 5 82 A
N 3 6409 6300 Battery contact spring (+) EF01DB20102 2 20 16 C
N 4 6409 6310 Battery contact spring (–) EF02DB10100 2 20 16 C
N 5 6409 6090 PCB ass'y DB20XX0300V*1 1 1 3,060 A
(This ass'y contains the above parts as its element.)
N 6 3122 2380 Buzzer EFB-S55C41A8 1 10 36 C
N 7 6409 6200 Lower case FABDB201004 1 5 61 X
N 7 6410 8340 Lower case (USA,CANADA) FABDB201012 1 5 70 X
N 8 6409 6210 Battery change label HGC00001102 1 20 7 X
9 6510 4440 Insulation seal HGFC0001206 3 20 6 X
10 6510 4500 Buzzer tape HGFC0000501 1 10 17 X
11 6512 1080 Nut MD100000602 3 20 15 X
12 6408 5920 Switch knob ass'y DB2AXX4A00M*1 1 10 30 C
N 13 6409 6220 Battery cover FADDB201001 1 20 29 X
N 14 6409 6230 Battery cover label HGC00001200 1 20 16 X
N 15 6409 6120 Battery holder ECDB1011108 2 20 26 X
N 16 6409 6130 Display panel EL5G0009107 1 10 48 C
N 17 6409 6140 Knob FB3DB201001 1 20 13 X
N 18 6409 6150 Battery insulation EL4C0001105 1 10 27 X
N 19 6409 6160 Mask tape HGG00012808 1 20 7 X
N 20 6409 6170 Rubber key LADB2010001 1 1 200 C
N 21 6409 6180 Upper case FAADB201008 1 1 120 C
N 22 6409 6190 Cushion FH100027108 2 20 10 X
23 6510 4310 Screw MAA80006311 2 20 3 C
24 6510 4350 Screw MAA80006302 1 20 2 B
25 6511 7160 RB Insert LC120000102 1 10 17 B
26 6511 8400 Key contact rubber LADB0220105 1 10 10 C
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
