44 : SF-4400
10. PARTS LIST 46 : SF-4600B
FOB Japan
N Item Code No. Parts Name Specification Q'ty M N.R.Yen R
44 46 Unit Price
10-1. PCB unit
LSI1 6409 2760 COB LSI C312133*1 1 1 1 1,010 A
LSI2 2011 2849 LSI (RAM) uPD43256AGU-1012LL 0 1 1 600 B
LSI3 2011 2849 LSI (RAM) uPD43256AGU-1012LL 1 1 1 600 B
Q1 2259 0959 Chip digital transistor DTC114YKT-146 1 1 20 12 B
DET1 2105 3297 CMOS IC S-80752AN-JG-T1 1 1 10 47 B
REG1 2105 3290 Regulator S-81253SGUP-DIJ-T1 1 1 5 60 B
N C1~4 2896 1645 Chip capacitor C2012JF1C474Z-TP 4 4 20 4 C
C5,6 2845 2534 Chip capacitor MCH185A180JK 2 2 20 4 C
C7,8,10,13 2845 1540 Chip capacitor MCH212F104ZK 4 4 20 4 C
N C9,11 2803 6806 Electrolytic capacitor 10MS510M-MW 2 2 20 13 C
C12 2845 1540 Chip capacitor MCH212F104ZK 0 1 20 4 C
D1 2390 2128 Chip diode MA740-(TX) 1 1 20 50 C
D2 2390 0364 Schottky diode MA713-TX 1 1 20 33 C
N R4 2797 3752 Chip resistor ERJ-6GEYJ000 1 1 20 3 C
R5 2791 1170 Chip resistor ERJ-6GEYJ182 1 1 20 3 C
R6 2797 0637 Chip resistor ERJ-6GEYJ473 1 1 20 2 C
N R7 2797 1309 Chip resistor ERJ-6GEYJ102 1 1 20 3 C
R8,9 2797 1078 Chip resistor ERJ-6GEYJ101 2 2 20 3 C
R10 2791 1871 Chip resistor ERJ-6GEYJ474 1 1 20 3 C
R12 2797 2520 Chip resistor ERJ-3GEAK206V 1 1 20 2 C
X1 7110 0642 Crystal oscillator DT-26S 1 1 1 57 B
JC1 3501 6538 Jack HSJ1169-012010 1 1 20 56 C
N 1 3335 4599 LCD CD773-TS 1 1 1 490 A
N 2 5610 7830 Heat seal L594AM C311912-2 1 1 1 110 A
N 3 6408 9410 Battery contact spring B C311911-2 2 2 20 6 C
N 4 6408 9400 Battery contact spring A C413028-2 2 2 20 19 C
34 6540 4970 Adhesive tape B-L571AM C411704-2 2 2 5 53 C
N 5 6408 9330 PCB ass'y C111198B*1 1 0 1 3,120 A
(This ass'y contains the above parts as its element.)
N 5 6408 9340 PCB ass'y C111198B*2 0 1 1 3,510 A
(This ass'y contains the above parts as its element.)
10-2. Mechanical parts for Taiwan product
6 3122 2380 Buzzer EFB-S55C41A8 1 1 10 36 C
N 7 6411 6090 Lower case FABDB101000 1 0 5 70 X
N 7 6411 6200 Lower case F1BDB101018 0 1 5 70 X
8 6409 6210 Battery change label HGC00001102 1 1 20 12 X
9 6510 4440 Insulation seal HGFC0001206 3 3 20 9 X
10 6510 4500 Buzzer tape HGFC0000501 1 1 10 17 X
11 6512 1080 Nut MD100000602 3 3 20 15 X
12 6408 5920 Switch knob ass'y DB2AXX4A00M*1 1 1 10 30 C
N 13 6411 6080 Battery cover FADDB100018 1 0 20 29 X
14 6409 6230 Battery cover label HGC00001200 1 1 20 16 X
15 6409 6120 Battery holder ECDB1011108 2 2 20 26 X
N 16 6411 6020 Display panel EL5C0011102 1 0 5 63 C
N 16 6411 6170 Display panel EL5C0011200 0 1 5 63 C
N 17 6410 9670 Knob FB3DB100001 1 1 1 130 X
18 6409 6150 Battery insulation EL4C0001105 1 1 10 27 X
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
— 25 —
