11. PARTS LIST
Quantity
N Item Code No. Parts Name Specification 4700L 4900L R
ABEF
LCD ASSY
N 1 6420 6170 HEAT SEAL A341754-1 1111B
N 2 3335 6617 LCD CD1126-TN(A) 1111B
PCB ASSY
LSI2, 3 2012 3192 LSI/S-RAM TC55257DFL-7085V 2200B
LSI4 2012 1659 LSI/S-RAM TC551001BFL-10V(S) 0011B
X1 7110 0642 OSCILLATOR/QUARTZ DT-26S 1111C
JCI 3501 6538 JACK HSJ1169-012010 1111C
N IC2 2105 5516
IC/MOS TC7W126FU-TE12L
1111
C
IC3 2105 1568
IC/MOS TC7S32F-TE85R
1111C
IC4 2105 4543
IC/MOS TC7W32F-TE12L
1100C
IC5 2101 1142
IC/MOS TC7W02F-TE12L
1111C
IC6 2105 3269
IC/MOS TC7W74F-TE12L
1111C
IC7 2105 1561
IC/MOS TC7S04F-TE85R
1100C
N IC8 2113 0374
IC/MOS D353-C
1111C
N IC9 2105 6385
IC/MOS
RH5RL53AA-T1 1111C
IC15 2105 1120
IC/MOS
TC7S08F-TE85R 1111C
Q1 2259 0959 TRANSISTOR/DIGITAL DTC114YKT-146 1111C
D1 2390 0847 DIODE/SCHOTTKY MA718-(TX) 1111C
D2 2390 0364 DIODE/SCHOTTKY MA713-TX 1111C
N 3 6420 6490 LCD ASSY A341805B*1 C 1111B
N
EL
6420 8020
ELECTRO LUMINESCENCE C442109-1
1111
B
N 4 6420 6160 SPRING/BATTERY A341753-1 3333X
5 6408 9410 SPRING/BATTERY C311911-2 3333X
COMPONENTS
N 6 6420 6150 PANEL/DISPLAY A341745-1 1000B
N 6 6420 6300 PANEL/DISPLAY A341745-2 0100B
N 6 6420 6350 PANEL/DISPLAY A341745-3 0010B
N 6 6420 6400 PANEL/DISPLAY A341745-4 0001B
N 7 6420 6080 CASE/UPPER A140694-1 1111X
N 8 6420 6130 KNOB A240986-1 1111C
9 6512 6040 CAP C311730-1 1111C
BZ1 3122 2380 BUZZER EFB-S55C41A8 1111C
N 10 6420 6210 HOLDER/BATTERY A442731-1 3333C
N 11 6420 6181 LABEL A442722A-1 1000X
N 11 6420 6311 LABEL A442722A-2 0100X
N 11 6420 6361 LABEL A442722A-3 0010X
N 11 6420 6411 LABEL A442722A-4 0001X
N 12 6420 6100 HARD COVER A140696-1 1000X
N 12 6420 6290 HARD COVER A140696-2 0100X
N 12 6420 6340 HARD COVER A140696-3 0010X
N 12 6420 6390 HARD COVER A140696-4 0001X
N 13 6420 6110 RUBBER/CONTACT A140697-1 1111C
N 14 6420 6050 PCB ASSY A140745*1 C 1100B
N 14 6420 6330 PCB ASSY A140745*2 C 0011B
15 6410 0150 SPRING/CONTACT C412167-2 1111C
N 16 6420 6120 KNOB A240985-1 1111C
N 17 6420 6140 COVER/BATTERY A240987-1 1111C
18 6410 0170 RUBBER/KEY C311028-3 1111C
N 19 6420 6220 CUSHION A442763-1 1111C
Parts prices will be informed separately by Parts Price List.
Notes: N – New parts
Q – Quantity used per unit
R – Rank
R – A :
B :
C :
X :
B:
A:
F:
E:
SF-4700L B.O.S.S
SF-4700L Others
SF-4900L B.O.S.S
SF-4900L Others
Essential
Stock recommended
Others
No stock recommended
— 22 —
