Casio SF-5590SY - 9 Parts List

9. PARTS LIST
N Item
Code No. Parts Name Specification Applicable Q R
PCB ASSY (A342054)
* There are two types of PCB ASSY (A342054) with SF-5790SY PLUS (I, J) and SF-5790SY (K, L)--A type & B type
NU5
2012 5867
LSI/ROM
CMO-03-ZX455 Common 1 B
U62
2012 5520
LSI/S-RAM
CMO-02-128NC-01 E,F,G,H 1 B
*U42, U62
2012 5520
LSI/S-RAM
CMO-02-128NC-01 I, J, K, L (A-type) 2 B
*U62
2012 5519
LSI/S-RAM
CMO-02-256SN-01 I, J, K, L (B-type) 1 B
U42, U62
2012 5519
LSI/S-RAM
CMO-02-256SN-01 M,N,O,P 2 B
U7 2114 5771
IC/TTL CMO-09-HC373 Common 1 C
U8 2114 5770 IC/TTL CMO-09-HC273 Common 1 C
N U12 2114 5827 IC CMO-13-D353C-01 Common 1 C
XT1 2590 2691 OSCILLATOR/CRYSTAL RER-01-12 Common 1 C
XT2 2590 2690 OSCILLATOR/CRYSTAL QUA-02-26 Common 1 C
N
D2~D5 2390 3031 DIODE/SCHOTTKY DIO-03-RB500V Common 4 C
D6~D17 2390 3005 DIODE DIO-01-LS4148 Common 12 C
N
D21,D22 2390 3030 DIODE/ZENER DIO-02-UDZ3.3B Common 2 C
L3 6420 1950 COIL/CHOKE C01-02-4615 Common 1 C
PCB ASSY (A342055)
N U2 2114 5828
IC/MOS
CMO-14-5VL22AA Common 1 C
N U3 3065 0712
CONVERTOR
CMO-10-R1502B Common 1 C
Q2 ,Q10, Q13
2259 2713 TRANSISTOR TRR-01-NPNL6 Common 3 C
N
Q3
2253 0711 TRANSISTOR TRR-01-2SD1628G Common 1 C
N
Q12
2254 0565 FET TRR-02-2S5204 Common 1 C
D1
2390 3005 DIODE DIO-01-LS4148 Common 1 C
N
D20, D22
2390 3032 DIODE/SCHOTTKY DIO-03-RB100A Common 2 C
L2
6419 6430 COIL/CHOKE COI-02-4630 Common 1 C
L4
3122 3509 INDUCTOR IND-01-120 Common 1 C
N
1
3502 2382 JACK JCK-01-1601 Common 1 C
2
6419 6460 SPRING/BATTERY BAC-01-988+ Common 1 X
3 6419 6470 SPRING/BATTERY BAC-01-988- Common 1 X
PCB ASSEMBLY
4
5610 9420 HEAT SEAL HES-03-ZX876A Common 1 B
5
5610 9430 HEAT SEAL HES-03-ZX876B Common 1 B
6
5610 9440 HEAT SEAL HES-01-161055 Common 1 B
7
3502 2224 HEAT SEAL HES-01-064065 Common 1 B
8
3335 6535 LCD/FSTN LCD-03-ZX876 Common 1 B
9
3312 0057 ELECTRO LUMINESCENCE LAM-03-ZX876 Common 1 B
N10
6421 3920 PCB ASSY A342054*1 HK E, F, G, H 1 B
N10
6421 3940 PCB ASSY A342054*3 HK I, J, K, L 1 B
N10
6421 3980 PCB ASSY A342054*7 HK M, N, O, P 1 B
N11
6421 4000 PCB ASSY A342055*1 HK Common 1 B
COMPONENTS
N
12 6421 4170 RUBBER/KEY(24-KEY) KEY-04-ZX455A-0 Common 1 C
N
13 6421 4190 COVER/PHONE JACK JCK-02-ZX455 Common 1 C
Notes:
E: SF-5590SY PLUS (include PC Link Floppy disk & Cable)
F: SF-5590SY PLUS (B.O.S.S. for E)
G: SF-5590SY (not include PC Link Floppy disk & Cable)
R- A: Essential
H: SF-5590SY (B.O.S.S. for G)
B:
I: SF-5790SY PLUS (include PC Link Floppy disk & Cable)
C: Others
J: SF-5790SY PLUS (B.O.S.S. for I)
X:
K: SF-5790SY (not include PC Link Floppy disk & Cable)
L: SF-5790SY (B.O.S.S. for K)
M: SF-5990SY PLUS (include PC Link Floppy disk & Cable)
N: SF-5990SY PLUS (B.O.S.S. for M)
O: SF-5990SY (not include PC Link Floppy disk & Cable)
P: SF-5990SY (B.O.S.S. for O)
N-New parts
R-Rank
Stock recommended
No stock recommended
— 30 —
