Casio SF-7900E Service Manual & Parts List

AT : SF-7900E
IT : SF-8900
PARTS LIST
JT : SF-8900 (B.O.S.S.)
FOB Japan
N Item Code No. Parts Name Specification Quantity M N.R.Yen R
AT IT JT Unit Price
CPU BOARD ASS'Y
C1 2803 6813 Capapcitor CB0011341R3
1
1 1 20 22 C
C4 2845 2289 Chip capacitor MCH215C471KK
1
1120 3 C
C5 2845 1673 Chip capacitor MCH215A221JK
1
1120 4 C
C6,C7 2845 2499 Chip capacitor MCH215A300JK
2
2220 3 C
C8,C9 6411 8550 Chip capacitor CP016F602T3
2
2 2 20 13 C
C10,11,16 2845 1540 Chip capacitor MCH212F104ZK
9
10 10 20 4 C
C81~87
C20 2845 3486 Chip capacitor MCH312F474ZP
1
1 1 20 21 C
D1 2390 0847 Chip diode MA718-(TX)
1
11 5 47 B
D2 2305 1028 Chip diode MA157-(TX)
1
0 0 10 34 B
N D2 2390 2338 Diode BC10SB007T4
0
11 5 64 B
D3 2390 0364 Shottky diode MA713-(TX)
1
1 1 10 33 B
IC2 2105 2982 IC S-80250AG-GB-T1
1
1 1 1 100 B
IC3 2105 2989 IC S-81220PG-PS-T1
1
1 1 10 45 B
IC4 2105 3794 IC, CMOS S-80766AL-EX-T1
0
11 5 70 B
IC4 2105 2247 CMOS-IC RH5VA60BA-T1
1
00 5 65 B
IC6 2105 1141 L-MOS IC TC4S66F-TE85R
1
11 5 39 B
N IC7 2114 3759 IC ABT7S080007
0
1 1 1 130 A
N IC8 2114 3752 IC ABT7S320008
0
1 1 1 130 A
J1 3501 6538 Jack HSJ1169-012010
1
11 5 56 X
LSI1 2011 3843 LSI HD62076C03
1
1 1 1 720 A
LSI2 2011 7350 LSI SSC2571FOA
1
0 0 1 460 A
N LSI2 2011 8393 LSI SSC2571FOB
0
1 1 1 460 A
LSI3, 4 2011 6300 LSI M5M51008AFP-10LL
1
2 2 1 1270 A
N LSI5 2011 9478 LSI UPD23C4001EBGW-J14
1
1 1 1 630 A
Q1 2221 0378 Chip transistor 2SC2812-L5, L6-TB
1
1 1 20 12 B
Q2 2200 4417 Transistor 2SA1179M5, M6-TB
1
1 1 20 15 B
Q4 2259 0959 Chip digital transistor DTC114YKT-146
1
1 1 20 12 B
R1,R2 2795 1309 Chip resistor MCR10EZHJ684
2
2210 9 C
R3,R22 2795 0532 Chip resistor MCR10EZHJ105
2
2220 3 C
R6,R7 2792 0217 Chip resistor MCR10EZHJ101
2
2220 3 C
R10 2792 0462 Chip resistor MCR10EZHJ473
1
1120 3 C
R12 2792 1191 Chip resistor MCR10EZHJ182
1
1110 9 C
R13,R31 2792 0470 Chip resistor MCR10EZHJ102
2
2220 3 C
N R14~R18 2775 1939 Chip resistor CC0512D10E8
5
5 5 20 13 C
R19 2792 0209 Chip resistor MCR10EZHJ104
1
1120 3 C
N R23 2775 1946 Chip resistor CC2201D11C3
1
1 1 20 13 C
N R24 2775 1953 Chip resistor CC3902D15E7
1
1 1 20 13 C
R25,R28 2795 0056 Chip resistor MCR10EZHJ000
2
0020 3 C
N VR1 6414 1300 Volume CF100230002
1
1 1 1 720 C
X1 2590 0777 Ceramic oscillator CSAC2.01MGCM001-TC
1
11 1 98 B
X2 6510 4550 Crystal BD0063P2509
1
11 5 55 C
1 6411 8490 Battery spring (+) EF01DB21109
3
3 3 20 12 X
2 6409 6310 Battery contact plate (-) EF02DB10100
3
3 3 20 16 X
N 3 6414 1280 CPU board ass'y DB21BX3100N*1
1
0 0 1 4,750 B
N 3 6414 1420 CPU board ass'y DB21CX3100V*1
0
1 1 1 6,000 AA
DISPLAY PCB ASS'Y
LSI6,7 2011 1974 LSI MSM6385AV-Z-358B
2
2 2 1 370 A
N 4 6414 1270 Display PCB ass'y DB21BX3F00U
1
1 1 1 940 J
Notes: N – New parts R – A : Essential
M – Minimum order/supply quantity B : Stock recommended
R – Rank C : Others
Q – Quantity used per unit X : No stock recommended
— 29 —
