Linear PCB No. 4

FOB Japan

N Item Code No. Parts Name Specification M N.R.Yen R

Unit Price

Q200 2252 0994 Chip 2SC4670-(TX) 10 23 C

Q204 2251 0189 Chip 2SB1218A-R(TX) 10 10 C

Q270 2259 1435 Chip DTC144EUWT106 10 9 C

Q750 2251 0189 Chip 2SB1218A-R(TX) 10 10 C

Q751 2259 1834 Chip DTA143TUWT106 10 15 C

Resistors

R100 2795 3360 Chip, Jumper MCR03EZHJ000 20 2 C

R105 2797 1995 Chip resistor ERJ-3GEYJ332V 20 10 C

R107 2797 1827 Chip resistor ERJ-3GEYJ333V 20 2 C

R108 2797 2464 Chip resistor ERJ-3GEYJ274V 20 2 C

R110 2791 1131 Chip resistor ERJ-6GEYJ271V 20 3 C

R113 2797 2044 Chip resistor ERJ-3GEYJ222V 20 2 C

R115 2797 1813 Chip resistor ERJ-3GEYJ101V 20 2 C

R117 2795 3360 Chip resistor MCR03EZHJ000 20 2 C

R160 2791 1692 Chip resistor ERJ-6GEYJ680V 20 3 C

N R200 2797 3689 Chip resistor ERJ-3GEYJ220V 20 2 C

R201 2797 1813 Chip resistor ERJ-3GEYJ101V 20 2 C

R202 2797 2247 Chip resistor ERJ-3GEYJ822V 20 2 C

R203 2797 2429 Chip resistor ERJ-3GEYJ392V 20 2 C

R204 2797 2394 Chip resistor ERJ-3GEYJ561V 20 2 C

N R205 2797 3689 Chip resistor ERJ-3GEYJ220V 20 2 C

R206 2795 3360 Chip jumper MCR03EZHJ000 20 2 C

R207 2797 2387 Chip resistor ERJ-3GEYJ391V 20 2 C

R208 2797 1869 Chip resistor ERJ-3GEYJ182V 20 2 C

R209 2797 2303 Chip resistor ERJ-3GEYJ103V 20 2 C

R210 2797 2065 Chip resistor ERJ-3GEYJ472V 20 2 C

R211 2797 1764 Chip resistor MCR03EZHJ104 20 2 C

R212 2797 2044 Chip resistor ERJ-3GEYJ222V 20 2 C

R214 2797 1862 Chip resistor ERJ-3GEYJ473V 20 2 C

R222 2797 2373 Chip resistor ERJ-3GEYJ470V 20 2 C

R223 7102 2193 Chip resistor ERJ-3GEYJ184V 20 2 C

R225 2795 3360 Chip jumper MCR03EZHJ000 20 2 C

R227 2795 3360 Chip jumper MCR03EZHJ000 20 2 C

R229 2797 1869 Chip resistor ERJ-3GEYJ182V 20 2 C

R230 2797 2394 Chip resistor ERJ-3GEYJ561V 20 2 C

R231 2797 2450 Chip resistor ERJ-3GEYJ153V 20 2 C

R236 2797 2464 Chip resistor ERJ-3GEYJ274V 20 2 C

R240 2797 2303 Chip resistor ERJ-3GEYJ103V 20 2 C

R241 2797 2457 Chip resistor ERJ-3GEYJ124V 20 2 C

R246 2797 2380 Chip resistor ERJ-3GEYJ331V 20 2 C

R247 2797 2044 Chip resistor ERJ-3GEYJ222V 20 2 C

R250 2797 2303 Chip resistor ERJ-3GEYJ103V 20 2 C

R270 2797 1827 Chip resistor ERJ-3GEYJ333V 20 2 C

R271 2797 2898 Chip resistor ERJ3GEYF473V 20 3 C

N R272 2797 3668 Chip resistor ERJ3GEYF512V 20 3 C

R275 2797 2030 Chip resistor ERJ-3GEYJ223V 20 2 C

R276 2797 1862 Chip resistor ERJ-3GEYJ473V 20 2 C

R280 2797 2030 Chip resistor ERJ-3GEYJ223V 20 2 C

R281 2797 2436 Chip resistor ERJ-3GEYJ562V 20 2 C

R282 2797 2394 Chip resistor ERJ-3GEYJ561V 20 2 C

R285 2797 2093 Chip resistor ERJ-3GEYJ271V 10 10 C

R286 2797 1764 Chip resistor MCR03EZHJ104 20 2 C

R301 2797 1862 Chip resistor ERJ-3GEYJ473V 20 2 C

R302 2797 2681 Chip resistor ERJ-3GEYJ393V 20 2 C

Notes: N – New parts

M – Minimum order/supply quantity

R – Rank

— 14 —
