— 3 —
Adjustment And Test Point Locations
Top View
T201
T200
ADJUSTMENT
LINEAR PCB
Items To Be Adjusted
Item Measuring Instrument
VCC2-1 voltage setting Voltmeter
Video detection coil adjustment TV signal generator, pattern generator, oscilloscope,
low-pass filter
AFT coil adjustment Sweep generator, oscilloscope, voltmeter
Contrast adjustment TV signal generator, pattern generator, oscilloscope
AGC adjustment TV signal generator, pattern generator, IF levelmeter
Clock adjustment Voltmeter
To Next Page
