Casio TV-5100B - Page 5

— 4 —
VR100
TP4
TP3
TP6
TP7
TP5
TP8
TP1
VR301
VR311
VR325
VR748
VR204
VR330
VR308
Pad IF
TP2
VCC2-1 Voltage Setting
Input Input Input Output Output
Connection Point Signal Connection Point
Adjust Result
Adjust for 4.50 ± 0.02 V
reading on voltmeter.
Voltmeter
VR100
Set
Output
Voltmeter
TP1
TP1
Equipment Connection / Adjustment Procedure
Bottom View
TV-5100
