Casio TV-5100B - Mechanical Parts List

FOB Japan
N Item Code No. Parts Name Specification Q N.R.Yen R
Unit Price
N 1 6609 2004 Speaker ass'y K412107*1 1 100 C
2 6607 4720 Cushion A-K614 K410316-7 1 7 C
N 3 6609 1530 Battery spring A-K610 K412012-1 10 35 C
N 4 6609 1520 Flat cable A-K610 K311586-1 1 29 C
5 6601 1700 Insulation tape A-K60 K4117-3 2 3 C
N 6 6630 5552 BL unit K211264*1 1 2,010 B
N 6-1 6609 2070 Shield case E-K610 K311634-1 1 28 C
N 6-2 6609 2080 Insulation plate B-K610 K41212-1 1 6 C
6-3 6607 0690 Insulation plate D-K508 K410441-3 1 7 C
6-4 6606 6201 Adhesive tape C-K502 K410903A-3 1 3 C
N 6-5 6609 2240 Shield case F-K610 K311674-1 1 26 C
N 6-6 6609 1330 Shield case C-K610 K311528-1 1 40 C
N 6-7 6609 1350 Reflection tape A-K610 K412014-1 1 13 C
N 6-8 6609 1340 Shield case D-K610 K311529-1 1 43 C
6-9 3851 1337 Fluorescent lamp 8.61AD1P2-CA4 1 340 B
6-10 3632 0308 Temperature fuse EYP-1BF102L 2 27 B
N 7 6630 5683 Battery cover ass'y K412106*1 1 520 C
8 6609 1320 Switch knob A-K610 K311527-1 1 20 C
N 9 6630 5684 Upper case ass'y K211263*1 1 630 C
N 9-1 6020 7658 Battery spring B1 G513 P408A-1 1 25 C
9-2 6606 4920 Battery spring C-K603 K410883-1 1 14 C
9-3 6020 7666 Battery spring B2 G513 P409A-1 1 23 C
N 9-4 6609 1400 Blind tape A-K610 K412066-1 1 16 C
N 9-5 6609 1390 Adhesive tape A-K610 K412015-1 1 18 C
10 6609 1360 Tuning button A-K610 K311521-1 1 20 C
N 11 6609 1480 Adhesive tape B-K610 K412016-1 2 15 C
N 12 6609 1490 Insulation plate A-K610 K412018-1 1 8 C
N 13 2725 0966 Display Unit TAD18T1001NB 1 4,000 B
N 14 6609 1370 Earth plate A-K610 K412013-1 1 30 C
N 15 6609 1410 Spacer for Display A-K610 K211183-1 1 55 C
N 16 6609 1270 Lower case A-K610 K110739-1 1 120 C
N 17 6606 2130 Stand A-K331 K310518-1 1 36 C
18 3851 1470 Rod antenna VR70100GA 1 180 C
N 19 6630 5685 PCB-K610B-L ass'y K211266*1 1 10,880 B
19-1 6604 7630 Insulation plate A-K332 K4670-17 1 3 C
N 19-2 6603 7100 Insulation plate B-K420 K4330-16 1 2 C
20 6609 1280 Display plate BAM-K610 K412011-2 1 160 C
N 21 6609 1300 Rating plate BAM-K610 K412010-2 1 10 C
22 5112 0868 Tapping screw (+) BT3, 1.7x5Bk 6 3 X
23 5860 0301 Tapping screw (+) BT3, 1.7x5Ni 3 3 X
24 5860 0805 Tapping screw (+) BT3,1.7x10Bk 2 3 X
25 5860 1477 Tapping screw (+) BT3,1.7x3.5Bk 1 1 X
N 26 6609 1290 Screw A-K610 K412031-1 1 3 X
Notes: N – New parts
M – Minimum order/supply quantity
R – Rank
MECHANICAL PARTS LIST
— 18 —
