Casio TV-770B - Waveforms

— 15 —
1 Q200 collector 2 IC200 pin 19 3 IC200 pin 18
4 IC300 pin 23 5 IC300 pin 12 6 IC300 pin 5
7 IC300 pin 4 8 IC300 pin 1
9 IC700 pin16
0 IC700 pin 14
63.5 µs 63.5 µs 63.5 µs
0.24 µs 63.5 µs 63.5 µs
63.5 µs 63.5 µs
130 ns
420 ns
2.0 V
0.8 V
0.1 V
0.8 V
1.8 V
3.0 V
3.0 V
0.8 V
3.0 V
3.0 V
WAVEFORMS
