Casio TV-880B - Parts List

PARTS LIST
LINEAR PCB
Item Code No. Parts Name Specification Q R
Diodes
D100 7101 1194 Chip diode MA111(TX) 1 C
D110 2360 2520 Chip zener diode MA8051-L(TX) 1 C
D150 7101 1194 Chip diode MA111(TX) 1 C
D152 2390 1379 Schottky diode MA729-(TX) 1 C
D155 2390 1470 Chip diode MA143A-(TX) 1 C
D180 2390 1190 Diode ERA15-01Y 1 C
D200 7101 1194 Chip diode MA111(TX) 1 C
D280 7101 1194 Chip diode MA111(TX) 1 C
D500 2360 3079 Chip zener diode MA8300-M(TX) 1 C
D701 7101 1194 Chip diode MA111(TX) 1 C
D801 2390 1477 Chip diode MA142WA-(TX) 1 C
D802 2390 1470 Chip diode MA143A-(TX) 1 C
D803 2390 1470 Chip diode MA143A-(TX) 1 C
Filter
F200 3025 1948 SAW filter SAF45MA210Z 1 C
F210 3025 1949 SIF filter SFSH4.5MCB 1 C
F220 3851 2105 Ceramic discriminator CDSH4.5MC30K 1 C
F230 3850 1259 SIF trap TPS4.5MB 1 C
Fuse
FU100 2797 5598 Chip fuse PI-R429.750 1 A
Oscillator
H300 25902731 Crystal oscillator HD-49-3.58M 1 C
ICs
IC100 2114 5867 IC TK11240BMCL 1 B
IC200 2114 1827 Linear IC M51348FP-T1 1 B
IC300 2114 3332 Linear IC M52042FP-T1 1 B
IC500 2116 0119 OP amplifier BA10358F-T1 1 B
IC600 2114 2464 Linear IC NJM2070M-T1 1 B
IC700 2012 6038 LSI ML9661GA-6006 1 B
IC710 2114 5866 IC S-81230SGUP-DQB-T1 1 B
Jacks
JK100 3501 8281 Power jack HEC0811-010010 1 C
JK250 3501 3773 Headphone jack HSJ6063-01-410 1 C
JK600 3501 5439 Jack HSJ1456-01-210 1 C
Transistors
Q101 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q110 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q111 2253 0308 Chip transistor 2SD1119-R(TX) 1 C
Q200 2250 1617 Chip transistor 2SC4417-(TX) 1 C
Q210 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q211 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q280 2259 2723 Digital transistor UN5211-(TX) 1 C
Q281 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q282 7101 5686 Digital transistor UN5111-(TX) 1 C
Q283 7101 5686 Digital transistor UN5111-(TX) 1 C
Q300 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q800 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q801 2253 0133 Chip transistor 2SD1819A-R(TX) 1 C
Q803 2251 0189 Chip transistor 2SB1218A-R(TX) 1 C
Q804 2251 0189 Chip transistor 2SB1218A-R(TX) 1 C
Notes: Q - Quantity per unit
R - Rank
— 8 —
