5. PARTS LIST: MODULE QW-2727/2730
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank -------------------------------
-
Very Important
B Rank -------------------------------
-
Important
C Rank -------------------------------
-
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basis.
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name Specification Applicable Q R
1010 9022 MODULE/WITH MOVEMENT QW-2727YCSA-01 WVA-400D-1A1V/1A2V 1 A
1010 5754
MODULE/WITH MOVEMENT
QW-2730YCSA-01 WVA-400DJ-1A1/1A2/9A 1
A
WVA-400TDJ-1A/9A
1 1010 3493 LCD C2730-01 QW-2727YCSA/2730YCSA Common 1 A
2 1010 6522 LED LNJ411K830CS QW-2727YCSA/2730YCSA Common 2 A
3a 7640 6322 PCB ASS'Y Q256086*1TK QW-2727YCSA-01 1 A
3b
7640 6222 PCB ASS'Y Q255907*1TK QW-2730YCSA-01 1
A
4 1001 0950 CAPACITOR/TRIMMER CTZ2E-30C-W2-P QW-2727YCSA/2730YCSA Common 1 B
5
7110 0715 OSCILLATOR/CRYSTAL DT-26SF
QW-2727YCSA/2730YCSA Common 1 A
6 7105 5275 SENSOR/TILT TS-2418-P QW-2727YCSA/2730YCSA Common 1 B
7 7640 6260 ANALOG BLOCK QW-2730MV-82TK QW-2727YCSA/2730YCSA Common 1 A
8 1006 5657 BATTERY/STORAGE CTL1616 QW-2727YCSA/2730YCSA Common 1 B
9 1010 3617 COIL ASS'Y Q371418*1 QW-2727YCSA/2730YCSA Common 1 A
10 1010 3618 COIL ASS'Y Q371419*1 QW-2727YCSA/2730YCSA Common 1 A
11 1002 7903 CONTACT/BATTERY
(
-
)
Q39603B-1 QW-2727YCSA/2730YCSA Common 1 C
12 7231 1777 HOLDER 1381 Q456843-1 QW-2727YCSA/2730YCSA Common 1 C
13 1011 7191 HOLDER/BATTERY Q255819B-2 QW-2727YCSA/2730YCSA Common 1 C
14 1010 6506 HOLDER/HOUR WHEEL Q372164-1 QW-2727YCSA/2730YCSA Common 1 C
15 1010 6521 INTERCONNECTOR Q470505-1 QW-2727YCSA/2730YCSA Common 1 C
16 1010 6512 LABEL Q471007-1 QW-2727YCSA/2730YCSA Common 1 C
17 1010 6516 LIGHT GUIDE Q372165-1 QW-2727YCSA/2730YCSA Common 1 C
18 1010 6517 LIGHT GUIDE Q372166-1 QW-2727YCSA/2730YCSA Common 1 C
19 1010 6519 REFLECTOR Q470501A-1 QW-2727YCSA/2730YCSA Common 1 C
20 7228 0511 SCREW Q422638-1 QW-2727YCSA/2730YCSA Common 3 B
21 1012 3230 SCREW RJQ513792-001V01 QW-2727YCSA/2730YCSA Common 3 B
22 1013 4221 SHEET/INSULATION RJQ515739-001V01 QW-2727YCSA/2730YCSA Common 1 C
23 1010 6520 SOLAR CELL BCS2926D5 QW-2727YCSA/2730YCSA Common 1 C
24 1010 6509 SPRING/COIL Q470503-1 QW-2727YCSA/2730YCSA Common 3 B
25 1010 6510 SPRING/COIL Q470504-1 QW-2727YCSA/2730YCSA Common 4 B
26 7201 9249 SPRING/COIL 675-3 Q413389A-1 QW-2727YCSA/2730YCSA Common 1 B
27 1010 6508 SPRING/LEAF Q372167-1 QW-2727YCSA/2730YCSA Common 1 C
28 7227 0294 WASHER/745 Q436294A-1 QW-2727YCSA/2730YCSA Common 1 C
29 7235 0913 WHEEL/HOUR 2315 Q364087B-1 QW-2727YCSA/2730YCSA Common 1 B
For the
p
rices and minimum order/su
pp
l
y
q
uantities of the above
p
arts, refer to the Parts Price List P.P.L.-595.
Notes: Q - Used quantity
R - Rank
— 16 —
