5.1) DIP-SWITCH S1 FUNCTIONS
DIP 1
ON
Automatic closing at the end of the work time-break after an opening controlled by the input of START.
OFF
Automatic closing after the work time-break excluded.
DIP 2
ON
Automatic closing at the end of the pedestrian time-break after an opening controlled by the input of
PEDESTRIAN
OFF
Automatic closing after the pedestrian time-break excluded.
DIP 3
ON
Active command inputs as START and PEDESTRIAN.
OFF
Active command inputs as OPEN and CLOSE separate
DIP 4
ON
Input radioreceiver RX1 it works as terminal block START.
OFF
Input radioreceiver RX1 it works as step-by-step.
DIP 5
ON
Same time of work for both the motors on M1.
OFF
Time of work separate and independent for both the motors.
DIP 6
ON
Power starting motors 3”.
OFF
Power starting motors 1,5”.
DIP 7
ON
Automatic closing at the end of the work time-break after an opening controlled by the input radioreceiver RX1.
OFF
Automatic closing after the work time-break excluded.
DIP 8
ON
Fast start motors (for barriers or up-doors) the motors after the impulse runs immediately.
OFF
Standard start motors (the motors after the impulse runs after few instant ).
DIP 9
ON
High speed in slow down
OFF
Slow speed in slow down
DIP 10
ON
Short closing impulse on.
OFF
Short closing impulse off.
5.2) DIP-SWITCH S2 FUNCTIONS
DIP 1
ON
Dead man working
OFF
IMPULSIVE working.
DIP 2
ON
Semiautomatic program. In opening it doesn't accept START impulses. It is possible to use it for the function
clock.
OFF
Program step-by-step: OPEN-STOP-CLOSE-OPEN
DIP 3
ON
Maximum power to the motors in closing in the last 2” on.
OFF
Maximum power to the motors in closing in the last 2" off.
DIP 4
ON
Power starting motors on.
OFF
Power starting motors of.
DIP 5
ON
In opening and time-break an impulse of Photocell 1 close again after 2."
OFF
Standard work on photocell 1 when the gate is closed and foto 1 obscurated ,the gate not open.
during the closing and foto 1 obscurated ,the gate stop and reopen when the foto1 is liberated (in this operation
is activated also the electrolock).
during the opening and foto1 obscurated ,the gate stop and reopen when the foto1 is liberated (in this operation
is activated also the electrolock).
DIP 6
ON
When the gate is closed, the START opens if PHOTOCELL 2 are obstructed.
OFF
When the gate is closed, the START doesn’t open if PHOTOCELL 2 are obstructed.
DIP 7
ON
Pre-alarm signal clinking 1 sec.
OFF
Pre-alarm signal clinking 4 sec.
DIP 8
ON
Output signal clinking intermittent.
OFF
Output signal clinking fixed.
DIP 9
ON
Working with 2 motors (type double leaf).
OFF
Working with 1 motor on M1 (type sliding gate or 1 leaf).
DIP 10
ON
Admittance to the planning menu
.
OFF
Disposition of the control panel in work condition.
5.3) DIP-SWITCH S3 FUNCTIONS
DIP 1
ON
Test photocells on FOTO 1 on.
OFF
Test photocells on FOTO 1 off.
DIP 2
ON
Test photocells on FOTO 2 on.
OFF
Test photocells on FOTO 2 off.
DIP 3
ON
Working type B
(it trains the card for signal clinking LAMP and it changes the work formality of the input Safety edge 1 and 2.).
OFF
Working type A (standard).
DIP 4
ON
Survey obstacle on motor 1 (reverse) off.
OFF
Survey obstacle on motor 1 (reverse) on.
DIP 5
ON
Survey obstacle on motor 2 (reverse) off.
OFF
Survey obstacle on motor 2 (reverse) on.
DIP 6
ON
Control power regulation of the of survey obstacle in deceleration on the motor 1 for a range of high power .
OFF
Control power regulation of the of survey obstacle in deceleration on the motor 1 for a range of low power .
DIP 7
ON
Control power regulation of the of survey obstacle in deceleration on the motor 2 for a range of high power
OFF
Control power regulation of the of survey obstacle in deceleration on the motor 2 for a range of low power
DIP 8
ON
The output light of courtesy is immediately disarmed at the end of closing.
OFF
The output light of courtesy is disarmed three minutes later than the end of closing.
DIP 9
They are not used.
DIP 10
They are not used.
