Page 3 of 14 EQ2006 R.1.5 Rev. 02 dated 09/11/2007
M8
17-18
Input N.C. PHOTOCELL 1.
Photocell trained in both the senses of march. The conditions of operation depends on S2 – dip 5.
17-19
Input N.C. PHOTOCELL 2. Photocell activates only in closing
(it arrests and it reopens).
The conditions of operation with the gate is closed depends on S2 - dip 6.
M9
20-22
Input N.C. LIMIT SWITCH OPENING 1.
Limit switch of opening of the motor 1.
If the motor is complete with limitswitches, you have to
connect them to the controlboard but not to the motor phases.
21-22
Input N.C. LIMIT SWITCH CLOSING 1.
Limit switch of closing of the motor 1.
22-23
Input N.C. LIMIT SWITCH OPENING 2.
Limit switch of opening of the motor 2.
22-24
Input N.C. LIMIT SWITCH CLOSING 2.
Limit switch of closing of the motor 2.
M10
25-28
Input N.C. STOP.
It arrests the movement of the gate.
26-28
Input N.O. START (S1 - dip 3 ON).
Input N.O. OPEN (S1 - dip 3 OFF).
27-28
Input N.O. PEDESTRIAN (S1 - dip 3 ON).
Input N.O. CLOSING (S1 - dip 3 OFF).
M13
29-30
Output warning light functions 24Vac.
It is out to when gate is closed , it has turned on when gate is open.
Output ELECTROLOCK; 12Vac, max. 1A.
M11
32-33
Output 24Vac to use for feeding the transmitting station of the photocells when the function "test photocells" is
activated.
Output 24Vac.
M12
35-36
Input aerial for radioreceiver RX
Aerial Cable to 36, eartn to 35.
Input external N.A. of RX1, GND 35
M14
37-38
Contact N.C. safety.
The opening of the contact removes the feeding from the spools of the relays disarming the outputs.
Clean contact of the 2° channel of the radioreceive r on the connection J1 RX.
WARNING : The inputs N.C. not used they must obligatorily be short-circuits toward the commune of the entries
CONNECTIONS J1 RX = graft for the receiver.
2) DIODE LED
Line of feeding; turned on to control panel fed
L2
SAFETY EDGE 1; it switch on to the intervention of the safety edge 1.
The flashing led L2 points out the condition of triac TH1 (pilot motor 1) in damage.
L3
SAFETY EDGE 2; it switch on to the intervention of the safety edge 2.
The flashing led L3 points out the condition of triac TH2 (pilot motor 2) in damage.
PHOTOCELL 1; it switch on to the intervention of the safety edge 1.
PHOTOCELL 2; it switch on to the intervention of the safety edge 2.
OPENING LIMIT SWITCH 1; it switch on to the intervention of the limit switch open of the motor 1.
CLOSING LIMIT SWITCH 1; it switch on to the intervention of the limit switch close of the motor 1;
OPENING LIMIT SWITCH 2; it switch on to the intervention of the limit switch open of the motor 2.
CLOSING LIMIT SWITCH 2; it switch on to the intervention of the limit switch close of the motor 2.
STOP; it switch on during the stop command.
RX1; it switch on during the impulse of the remote control.
START; it switch on during the start command.
PEDESTRIAN; it switch on during the pedestrian command.
L14
REV 1; it switch on red to the intervention of the reverse on the motor 1 during the work and it visualizes the last
seconds of the stroke turning on itself green.
L15
REV 2; it switch on red to the intervention of the reverse on the motor 2 during the work and it visualizes the last
seconds of the stroke turning on itself green.
L16
SET; it marks the regular operation of the microprocessor of the control panel with some green continuous
lightning during the work.
3) DEVICES OF PLANNING
The pushes button PS1s (START), PS2 (Pedestrian), PS3 and the leds L14, L15, L16 are used for the formulation of the parameters
in the planning menu (see chapter 6).
4) CONTROLS POWER
It set the power of the motor 1.
It set the power of the motor 2.
P2
It set the sensibility to the obstacle while motor 1 is
working.
P5
It set the sensibility to the obstacle while motor 2 is
working.
P3
It set the sensibility to the obstacle while motor 1 is
slowing down.
P6
It set the sensibility to the obstacle while motor 2 is
slowing down.
