ELECTRICAL DIAGRAMS
DIAGRAMAS ELECTRICAS
FS-2000 Battery Scrubber (11--01)
34
24V WIRE
DIAGRAM
BRUSH
MOTOR
12V BATTERY 12V BATTERY
35 AMP
BREAKER
SWITCH
VACUUM
MOTOR
SAFETY LIGHTS
24V D.C.
FLASHER
CONDUIT
SOLENOID
CONDUIT
CHARGER
PLUG
1
2 3
BRUSH
SWITCH
BATTERY METER
VACUUM
SWITCH
BLK 12
RED 12
BLK 14
BLK
BLK
BLK 10
RED 8
RED 10
RED 10
RED 18
RED 8
BLK 16
BLK 18
RED 14
RED 8
BLK 16
RED 14
RED 10
RED 18
BLK 18
BLK
BLK 18
RED 18
RED 18
RED 14
RED 18
RED 16
BLK 18
