PARTS LIST
LISTA DE PIEZAS
FS-2000 Battery Scrubber (10--04)
49
NON-DRIVE MODEL WHEEL GROUP
CONJUNTO PARA LEVANTAR CEPILLO
REF PART # DESCRIPTION QTY.
1 230874 LEVER, BRUSH LIFT FOOT 1
2 200816 GRIP, HANDLE 1
3 102560 PAD, NON--SLIP 1.62 SQ. 2
4 140509 NUT, 1/2--13 HEXJ AM 4
5 140045 W ASHER, .510X1.25X.06 FLAT 10
6 140139 SLEEVE, 0.625D 0.50B 0.25L STL 6
7 140024 WASHER, 1/2 LOCK 3
8 140236 SCREW, .50--13 X 1.25 5
9 230870 WELDMENT, LIFT BRACKET 1
10 02931 NUT, HEX .50 --13 LOCK NY 2
11 230869 BRACKET, AXLE & SQ PIVOT MNT 2
12 140024 WASHER, LOCK 0.50 4
13 140237 SCREW, HEX .50 --13 X 1.00 6
14 140045 WASHER, .510X1.25X.06 FLAT 2
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
15 02991 SCREW, HEX .31--18 X 0.75 2
16 140433 SPRING, EXT .50 X 3.00 2
17 140506 NUT, 5/16 --18 HEX 2
18 02994 SCREW, HEX .38--16 X 0.75 2
19 140017 WASHER, LOCK SPLIT 0.38 2
20 140028 WASHER, FLAT .38 2
21 1012022 DWHEEL 8”X1.5” 2
22 230743 SHAFT, AXLE .75D 166L 1
23 140234 SCREW, 1/2--13X2--1/2 HXHDCP 1
24 3148.816 WASHER, 0.52B 0.88D .06 1
25 140430 SPRING, HANDLE LOCK 1
26 140127 BEARING, THRUST 2
27 230871 BRACKET, MOTOR MOUNT 1
28 130040 WIRE TIE, NYLON 1
