OPERATION
SCX-2800 (08–03)
7
CONNECTING MACHINE TO POWER SOURCE
1. Connect equipped extension cord to short pigtail
cord on machine.
2. Plug extension cord into a grounded power outlet
(Figure 5).
FOR SAFETY: Do not operate machine unless
cord is properly grounded.
FOR SAFETY: Do not operate machine with the
use of additional extension cords. Only use
manufacturer’s extension cord equipped with
machine which has proper capacity and is
grounded.
Grounded
3 Hole Outlet
Ground Pin
FIG. 5
WARNING: Do Not Operate With Damaged
Power Cord. Do Not Modify Plug. Unplug power
Cord Before Servicing Machine.
If the supply cord is damaged or broken, it must
be replaced by the manufacturer or it’s service
agent or a similarly qualified person in order to
avoid a hazard.
3. Attach belt clip to power cord and to your belt
(Figure 6).
FIG. 6
PRE–OPERATION CHECKS
1. Vacuum the floor and remove any debris.
2. Inspect the power cord for damage. Replace
immediately if damaged.
3. Check that the spray bar is installed.
4. Inspect the spray tips for proper spray pattern
(See MACHINE MAINTENANCE).
CLEANING CARPET
FOR SAFETY: Do not operate machine unless
operator manual is read and understood.
WARNING: Do Not Pick Up Flammable
Materials Or Reactive Metals.
WARNING: Do Not Use Flammable Liquids Or
Operate Machine In Or Near Flammable Liquids,
Vapors Or Combustible Dusts.
1. Turn on main power switch.
2. Turn vacuum switch on.
3. Lower brush by depressing thumb latch and
moving lever forward (Figure 7).
FIG. 7
4. Turn pump switch on.
NOTE: Pump and brush are activated by the control
grips.
