9 Machine Adjustments
9.1
Using the Thin Stock Overlay Plate for Thinner Stock
The Castle-100 is factory adjusted for 5/8 inch and thicker stock. To machine 1/2
inch to 5/8 inch stock, an overlay plate is provided. Simply push the clear plate onto
the work deck of the Castle 110 as shown in figure 9a. Follow the instructions in
section 6 for setting the clamp pressure and cutting the pocket.
