TSM-35 Screw Pocket Machine Troubleshooting
35.16 Test Stock Sense / Safety Blade Switch
• Disconnect power and air to the machine.
• Make sure the case top is shut.
• Locate pins “5” and “6” on the pin strip in the control box.
• Touch continuity tester to “5” and “6” on the pin strip.
• Continuity tester should read open.
• Press in safety buttons under the clamp guard and tester should read closed.
