Technical CATERPILLAR – 1000 kVA Page
25
Description UTILITY POWER MODULE
Revision 1.0 1 May 2006
Notes:
1. Temperature indications are viewable in either °C or °F (operator selectable).
2. Pressure indications are viewable in psi, kPa, or bar.
3. Fuel Consumption viewable in US/Imperial gal/hr or Liters/hr.
4.6.3. Warning/Shutdown indication
• Overcrank
• Low Coolant Temperature Warning
• High Coolant Temperature Warning/Shutdown
• Loss of Coolant Warning/Shutdown
• Low Oil Pressure Warning/Shutdown
• Overspeed
• Control Switch Not In Auto
• High/Low Battery Voltage
• Emergency Stop Activated
• Low Fuel Pressure Warning/Shutdown
• High Fuel Pressure Warning/Shutdown
• Fuel Filter Restriction Warning/Shutdown
• High Intake Manifold Air Temperature Warning/Shutdown
• High Oil Temperature Warning/Shutdown
Notes:
• Warning condition activates common alarm output signal and common flashing yellow
indicating lamp.
• Shutdown condition activates common alarm output signal and common flashing red
indicating lamp.
• Warning/Shutdown conditions result in text message on EMCP 3 display.
4.6.4. Digital inputs (8 Total)
• Emergency Stop
• Remote Start
• 6 Programmable
Digital inputs can be programmed for various alarm, shutdown, and status conditions
including: Low Fuel Level, High Fuel Level, Fuel Leak Detected, High Exhaust Temperature,
Air Damper Closed, Circuit Breaker Open/Closed, Low Engine Oil Level, Low Coolant Level,
Low Starting Air Pressure, Low/High Ambient Air Temperature, Spare Fault #1-6. Inputs can
be programmed for either high or low activation using programmable Normally Open or
Normally Closed contacts.
4.6.5. Protective relaying
• Generator Over/Under Voltage
• Generator Over/Under Frequency
