Technical CATERPILLAR – 1000 kVA Page
28
Description UTILITY POWER MODULE
Revision 1.0 1 May 2006
5. CONTAINER
5.1. General description
The module is contained in an industry standard 20 foot (6 m) high-cube container. The
container is sound attenuated to meet 85 dB (A) at 7 m prime power. It’s Lloyds CSC
(Convention for Safe Containers) certified for convenient transport and stackable up to 3 high
for transport and storage.
5.2. Features
• New container with checkered steel deck on floor. Interior walls and ceiling are
insulated with 50 mm (2 in) of acoustic glass and covered with perforated galvanzed
steel for a durable interior wall surface.
• Three personnel doors provided with sound attenuation and double sealed. One door
located on each side of the engine and one in control room. Includes stainless steel
hardware and hinges and panic release.
• External access door provided for bus bars and auxiliary connections (jacket water
heaters, battery charger, space heater in generator and optional interior loads).
• Two 24 VDC interior lights with 60 min. timer in switchgear room and 3 in engine
room.
• AC / DC Distribution and Motor Control Assembly includes the following distribution
IEC rated breakers for Power Module accessories:
o 1 # 10A, two (2) pole # Battery Charger input
o 1 # 15A, single pole - AC Lighting Controls.
o 3 # 15A, two pole # Generator Space Heater, Receptacles and Lighting.
o 1 # 20A, single pole # Switchgear DC Control Power.
o 2 # 30A, two pole # Jacket Water Heater #1 & #2.
• Duct Silencers for engine room and radiator room
