CAT C32 - Page 35

Technical CATERPILLAR – 1000 kVA Page 35
Description UTILITY POWER MODULE
Revision 1.0 1 May 2006
FACTORY INSTALLED STANDARD EQUIPMENT (Continued)
Feature
Switchgear The monitoring system includes a mimic one line that shows the generator with it's
Monitoring respective circuit breaker in a one-line representation of the system. The graphic
COLOR LED indicators display the following information:
- Generator circuit breaker open/closed/tripped
- Engine running
- System summary alarm
The monitoring system also includes an additional display conveniently monted in the
EMCP 3.3 panel. This display is a 4 line text display with pushbuttons for various
controls. This display provides quick module set up with all parameters
stored in non-volitile memory. In addition to individual module information,
each module also provides overall plant information including:
overall power production; and alarm / shutdown status of each MODULE.
The control system monitors and manages various module functions. This includes
the automatic lube oil make up system, alarms and emergency stop functions.
The 693 frame generator is provided with winding temperature sensors as standard.
The control system monitors and displays these values, providing alarm and
shutdown. Various diagnostic features are provided including breaker synchrnonizing
time out and reclose alarms, circuit breaker posistion feedback,
phase rotation mismatch, network communication error alarms,
sensor diagnostics, and multiple unit configuration checks.
Switchgear MONITOR AND PROTECTION FUNCTIONS
Protection
- Generator over current ANSI 50 / 51
- Neutral earth current ANSI 50 / 51 (requires optional CT)
- Generator current imbalance ANSI 46G
- Generator under voltage ANSI 27G
- Generator over voltage ANSI 59 G
- Generator voltage imbalance ANSI 18 G
- Generator leading power factor
- Generator lagging power factor
- Generator under frequency ANSI 81 U/G
- Generator over frequency ANSI 81 O/G
- Generator reverse power ANSI 32 G
- Generator overload ANSI 32 O / G
- Busbar under voltage ANSI 27G
- Busbar over voltage ANSI 59 G
- Busbar voltage imbalance ANSI 18
- Busbar under frequency ANSI 81 U
- Busbar over frequency ANSI 81 O
