KNOW YOUR LIFT TRUCK
◆◆
Drawbar Pin
Use the drawbar pin for:
– Pulling the truck out of a drop-off or ditch.
– Loading the truck on a hauling truck.
1. When hitching a cable to the pin, make
sure the pin is inserted safely.
2. Take up slack slowly—DO NOT jerk. Keep
the cable taut. If the cable is slack, the sud-
den impact of the load can snap it, resulting
in an accident.
3. A helper should stand at a safe distance and
watch the pin. Stop pulling with the truck,
relieve tension, and reduce load if the pin
starts to come out.
Grasp the assist grip with the left hand, the seat
backrest with the right hand, and step up with
the left foot to get on the truck safely.
DO NOT use the drawbar pin for towing
loads.
DO NOT grab the steering wheel or lever.
DO NOT jump on or off the truck.
Precautions for Use of the Drawbar Pin
100864A
◆◆
Assist Grip
101644
Drawbar pin
103242
WARNING
!
WARNING
!
WARNING
!
