4242
KNOW YOUR LIFT TRUCK
The oil level/filler hole is located on the right
side of the truck inside the engine hood. To
check the oil level, use the dipstick located in
the hole.
The fuel filler is located on the left side of the
truck. The cap can be removed by turning it
counterclockwise.
The fuel shut-off valve is located near the air
cleaner inside the engine hood. In an emer-
gency or when performing maintenance, close
this valve.
Never fill the tank near an open flame or when
the engine is running. When filling, keep the
funnel or fuel hose nozzle in contact with the
tank’s metal. This reduces the risk of an electric
spark igniting the fuel.
After refueling, close the cap tightly and wipe
up spillage.
◆◆
Fuel Filler
Confirm the engine type before filling the
tank with the recommended fuel.
103196
103197
100989
102538
◆◆
Hydraulic Tank Oil Level/Filler Hole
◆◆
Fuel Shut-off Valve
103938
Close
Open
CAUTION
!
WARNING
!
WARNING
!
