1. Park the truck on level ground with parking
brake applied, transmission in neutral,
forks lowered and engine stopped.
2. Prepare tools, jack and wheel blocks.
Jack Capacities
3. Block the diagonally opposite wheel.
1. Loosen the wheel nuts about two rotations.
NOTICE: Only loosen the wheel nuts. DO
NOT remove them.
2. Position the jack under the truck at the
specified jacking point.
3. Raise the truck by operating the jack until
the tire just clears the ground.
To Remove Tire
100829
100830
100902B
7 tons (16000 lbf), minimum
Wheel nut
Tilt
forward
Block
Tilt backward
Position the jack under the frame and raise the
truck until the front tire clears the ground.
Next, place stands or blocks of wood on both
sides under the frame to support it.
Tilt the mast all the way back, place blocks
under the mast, and tilt the mast forward.
To Raise Front Tire
Other Method
100913
TROUBLESHOOTING
101106
• Single Tire
